2.15mm*5.95mm paper covered copper kraft wire,resist temperature
TEST REPORT
Name |
2.15mm*5.95mm paper covered copper wire |
|||
Specification |
2.15mm×5.95mm |
|||
Standard |
GB/T7673.3-2008 |
|||
Test Item |
Unit |
Technical requirement |
Test result |
|
Appearance |
|
Uniform formation around the conductor, there should be no shortage of tape layers should not have wrinkles and cracks and other defects |
No defects
|
|
Size |
Thickness(a) |
mm |
±0.03 |
2.15 |
Width(b) |
mm |
±0.05 |
5.95 |
|
Insulation thickness |
mm |
0.405---0.45----0.48 |
0.48 |
|
Electrical Resistance(20°C) |
Ω.mm2/m |
Copper≤0.017241 |
0.01700 |
|
Springback angle |
º |
≤5º |
4.8 |
|
Wrapping overlap |
mm |
≥2 |
2 |
|
Elongation |
% |
Size a ≤2.5 30% >2.5 32% |
49% |
|
Winding bend |
|
Negotiated |
No alice |
|
packing |
Meet export standard |
|||
Result |
Up to standard |
|||
Good feature
l High dielectric strength
l Good temperature strength
l Level wrapping
Material
Drawing or Squeezing bare wire confirm national standard. smooth surface, no defect
Standard
l GB/T5584-99
l NEMA-MW60-A
Application
l Transformer
l Welding machine
l Electric reactor
Certificate
UL BV IEC ROHS
Production process
l Sample is free,its shipping time is 3-5days.
l The phone is on-line all day.
Brief introduction
Located in Yanling County, Henan Province Of China,Huayuan was established in 1993,has developed a professional manufacturer of Magnet Wires in China,and our products conform the standards of IEC, NEMA ,ROHS,ISO9001,UL.
We implete 5S management.
You can choice other products.
