class 220 fiber glass covered wire
- 500 Ton / Tons per Month
- Shanghai Tianjin Qingdao
- T/T D/P D/A Credit Card
- Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
- Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
- XTW CXWT 300V UL62 PVC FIexible Cord
- Enameled Copper wire
- 3x185mm2 Overhead Insulated Cable
- Service Drop Cable XLPE/PVC/PE Insulated
Product Details
Place of Origin: | Henan, China | Brand Name: | HUAYUAN | Model Number: | GLEMB-HY-D |
Type: | Insulated | Application: | Other, compressor motors, power tools, | Conductor Material: | Copper |
Conductor Type: | Other, class 220 fiber glass covered wire | Insulation Material: | Fiberglass |
Product Description
Specifications
class 220 fiber glass covered wireDiameter: a:1-6mm b:3-16mm
Standard: IEC, NEMA, ISO
Thermal Class: 130/155/180/200/220
class 220 fiber glass covered wire
Specifications of class 220 fiber glass covered wire
Diameter: a:1-6mm b:3-16mm
Standard: IEC, NEMA, GB
Thermal Class: 130/155/180/200/220 centigrade
Certification: BV, UL Approved,ISO9001, ROHS
class 220 fiber glass covered wire Performance features
1) High heat resistance
2) Excellent adherence and flexibility
3) Good solvent resistance and electrical properties
4) Excellent mechanical properties
5) Stable performance
Material of class 220 fiber glass covered wire
1) Bare copper wire or squeeze bare flat wire confirm the National Standard, smooth surface, low resistance
2) Polyimide film (nonwovens) and fiberglass as wrapping material
Product Description | Temperature Class Degrees C |
Glass & Film Glass & Polyester Glass Polyester Glass & Film | Class 155 Insulating Varnish |
Aromatic Polyamide | Class 200/220 |
Polyimide Tape | Class 220 |
Packing about class 220 fiber glass covered wire
Inner packing: different plastic spool according to wire diameter (Plastic spool of PT-4,PT-10,PT-20,PT-25)
Outer packing: wooden cases or according customers' requirement.
test report of class 220 fiber glass covered wire
Name | class 220 fiber glass covered wire | ||||
Type | GLMEB-0.45155 | ||||
Diameter | 2.24X4.50mm | ||||
Standard | GB/T7672.4 | ||||
Test Item | Unit | Technical requirements | Test Result
| ||
Appearance |
| Bright and clean, uniform color | Ok | ||
Dimensions | Bare Conductor | Narrow side | mm | ----- | ----- |
Broad side | mm | ----- | ----- | ||
Enameled Increase | Narrow side : | mm | ±0.03 | 2.25 | |
Broad side | mm | ±0.05 | 4.51 | ||
Adherence and Flexibility | Winding Test |
| 10b,10a no cracking | OK | |
Adherence Test |
| 10% No Crack, and No losing adhesion | OK | ||
Resistivity(20°C) | Ω. mm²/m | ≤0.017241 | 0.01713 | ||
Elongation | % | A side(mm) ≤2.5 30% >2.5 32% | 42% | ||
Breakdown Voltage at Room Temp. | V | 560 | 804,759,762,688 | ||
Packing |
| Meet the export standard | OK |
Manufacturing process of class 220 fiber glass covered wire
Test equipment
Application
Certificate
7. Best service
1) .Trail order is welcomed, you can test our quality before making large quantity, even though we are wholesales supplier
2). We issued test reports for every shipment.
3). You can enjoy discounting and priority to produce first after you become to be our regular client.
8.Company Advantage
1). About 20 years manufacture experiences
.
2). class 220 fiber glass covered wire been Audit by UL Company and BV Company
3).We have a big Quality Control Team and can guarantee the quality and time of delivery
Many trade companies place orders from us.
