Home > Industrial Equipment & Components > Conveyor & Parts > Conveyor > CQD-B Reach Stacker

CQD-B Reach Stacker

Name: CQD-B Reach Stacker
Brand: SINOLIFT
SKU: 132449207

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

SINOLIFT

Model Number:

CQD-B Reach Stacker

Contact Supplier Request Quote Chat Now

Shanghai Sinolift Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name SINOLIFT

Model Number CQD-B Reach Stacker

After-sales Service Provided Engineers available to service machinery overseas

Specifications

CQD-B Reach Stacker
1.Capacity: 1000/1500kg
2.Max.lift height: 3000mm

CQD-B Reach Stacker

1)Features

1.Excellent Turning Radius.
2.Equipped With European top quality Driving wheels, Electronic Control system, etc.
3.High Maneuverability even in narrow aisle.
4.Innovative design adopting two hydraulic cylinder, provides excellent visibility.
5.Operator's position was ergonomically designed with footplatform or Armrest for confort and safety.

2)Specification Date

Model		CQD-10B	CQD-15B
Rated from the weight of Q(kg)	kg	1000	1500
Load center distance L3(mm)	mm	400(500)	400(500)
Enhance the high degree of	mm	3000	3000
Free upgrade	mm	(150+1500)	(150-1600)
Fork length	mm	800(1000)	800(1000)
Lifting the form of		Electro-hydraulic type	Electro-hydraulic type
Lifting speed	m/min	>5m	>5m
The rate of decline	m/min	Adjustable	Adjustable
Gantry angle before / after		2^o/5^o	2^o/5^o
Height gantry	mm	2000	2000
Maximum height of the door or set up	mm	3500	3500
Drive the form of		Electric Wheel	Electric Wheel
Walking speed (full load / no load)	km/h	5/4.5	5/4.0
Speed control		Promise speed regulation system	Promise speed regulation system
Gradeability	%	8/5	8/5
Traveling brake		Battery brake	Battery brake
Batteries	24V	D-240	D-400

3)Photos

4)Workshop

5)Certificate

Shanghai Sinolift Equipment Co., Ltd is a production, design, manufacture, sales and service in one integrated production and trade enterprises. Main types of forklifts, material handling, storage and lifting products, also offer a variety of wire harnesses, TFT rule processing business, and produce a variety of OEM memory cards. Products are used in Germany and Japanese technology, all products passed "TUV", "CE", "GS" and "ISO9001" international quality system certification, the application of new technologies has unique.

6)Terms and Service

Lead time	3-4 weeks
Packing	Standard export fumigated wooden pallet, foam rubbers
Payment term	T/T payment in advance; L/C at sight
Lead term	FOB Shanghai or CFR/CIF
Warranty period	12 months
Shipping method	by sea or air; by express

7) Warranty Policy and Service Program

SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.

Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.

If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.

SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items
