2016 SINOLIFT NP50 Heavy Duty Hand Pallet Truck with Good Quality
- 200 Unit / Units per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Stable performance computer Board Recycling Machine
- Lithium Ion Battery Recycling Machine For Black Mass And Metal
- Cement dry ash bulk machine telescopic ring cloth bag DN300/600 thickened wear-resistant
- Homogenization tank B200 external fluidization plate homogenization tank inflation equipment
- B400 Electro-hydraulic sector valve Pneumatic sector valve Block material sector valve can be customized
- Bulk material bulk hangar bottom cement clinker sand aggregate loading inside the wear-resistant ceramics
Product Details
Place of Origin: | Shanghai, China | Brand Name: | SINOLIFT NP50 Heavy Duty Hand Pallet Truck | Model Number: | NP50 Heavy Duty Hand Pallet Truck |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
2016 SINOLIFT NP50 Heavy Duty Hand Pallet Truck with Good Quality
1)Features of NP50 Heavy Duty Hand Pallet Truck
Quality engineered for strength, dependability and long life. SINOLIFT's choice as the pallet jack on the market today. Standard models come with a standard capacity of 2500 Kg.
The hydraulic system on this pallet jack is the result of years of research and development, including a load limiter that prevents premature wear resulting from overloading. A special design of lowering valve permits gentle lowering of heavy loads. No moisture can get into the unit and it is leak proof.
Lifting - Neutral - Lowering. No foot pedal means extra safety. Neutral allows pumping at the most convenient angle to the operator and free handle movement when the truck is in motion. The handle returns automatically to the vertical position.
All Parts guranteed for a full year, except where used in Acidic or Alkali Environments.
2)Specification of NP50 Heavy Duty Hand Pallet Truck
MODEL | NP50-510 | NP50-712 | |
Rated Capacity (Kg) | 5000 | 5000 | |
Width over forks (mm) *1 | W | 520 | 685 |
Fork length (mm) *1 | L | 1070 | 1220 |
Min. Fork Height (mm) | H2 | 80 | 80 |
Max. Fork Height (mm) | H1 | 200 | 200 |
Steering Wheel (mm) *2 | A | 200x62 | 200x62 |
Load Wheel (mm) *3 | B | 78x70 (Tandem) | 78x70 (Tandem) |
Weight (kg) | 80 | 83 | |
Under Clearance (mm) | 40 | 180 | |
Fork width (mm) | W2 | 160 | 160 |
Width inside forks (mm) | 200 | 365 | |
Stroke length (mm/stroke) | 10 | 10 | |
Overall Height (mm) | 1248 | 1248 | |
Overall Length (mm) | 1500 | 1570 | |
Steer Angle | 210 deg | 210 deg | |
Drive Unit Length (mm) | 400 | 400 |
3)Pictures of NP50 Heavy Duty Hand Pallet Truck
4)Workshop
5)Certificates
6)Terms and Service
Lead time | 3-4 weeks |
Packing | Standard export fumigated wooden pallet, foam rubbers |
Payment term | T/T payment in advance; L/C at sight |
Lead term | FOB Shanghai or CFR/CIF |
Warranty period | 12 months |
Shipping method | by sea or air; by express |
7) Warranty Policy and Service Program
SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.
Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.
8) Why choose us?
1- We're a material handling company, a pioneer in the industry in China, we've been leading the Chinese warehouse equipment industry since 2001. Sinolift products have been delivered to more than 80 countries.
2- We are unique. We are not assembling, 95% core parts are produced by ourselves. And Sinolift is keeping on investing 30% of its margin on R&D.
3- Strict Quality Control: 48 hours 100% inspection of electronic parts test, 100% Quality Control before delivery.
