Sinolift FSJY Series Auto Self-propelled Electric Scissor Lift

Name: Sinolift FSJY Series Auto Self-propelled Electric Scissor Lift
Brand: SINOLIFT
SKU: 132436835

Sinolift FSJY Series Auto Self-propelled Electric Scissor Lift thumbnail-1

Sinolift FSJY Series Auto Self-propelled Electric Scissor Lift photo-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

SINOLIFT

Model Number:

FSJY0608/0810/1012/1214

Contact Supplier Request Quote Chat Now

Shanghai Sinolift Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name SINOLIFT

Model Number FSJY0608/0810/1012/1214

After-sales Service Provided Engineers available to service machinery overseas

Sinolift FSJY Series Auto Self-propelled Electric Scissor Lift

1) Features

The lifting platform has the function of automatic stepping and turning, with non-manpower draught and non-external power source. It is flexible and convenient for moving for aloft work, which is the ideal aloft working facility for safety production in modern enterprise. All models of shears-fork type aloft working platform can be changed to the automatic hydraulic lifting platform.

1. High-quality construction steel.

2. Braking/manual optional.

3. The shears-fork mechanical structure provides higher stability when the platform elevating. On the other hand, the wide working platform and higher loading capacity are suitable for various aloft work requirement, and multi-persons operation at the same time.

4. It is mainly applied for factory, warehouse, bus station, dock, airport, in aloft working, commodity convey, assembly line corollary equipment, and etc.

5. Equipped with over-load safety device, protection device for hydraulic pipe bursting, and emergency descent device, which increase safety for operation.

2) Specification Data

Model		FSJY0608	FSJY0810	FSJY1012	FSJY1214
Max. working height	mm	8000	10000	12000	13800
Max. platform height	mm	6000	8000	10000	11800
Folding max. height (guardrail unfolding)	mm	2150	2275	2400	2525
Folding max. height (guardrail removed)	mm	1190	1315	1440	1565
Overall length	mm	2400	2400	2400	2400
Overall width	mm	1150	1150	1150	1150
Platform size	mm	2270x1150	2270x1150	2270x1150	2270x1150
Platform extend size	mm	900	900	900	900
Min. ground clearance (folding)	mm	110	110	110	110
Min. ground clearance (rising)	mm	20	20	20	20
Wheelbase	mm	1850	1850	1850	1850
Min. turning radius (inner wheel)	mm	0	0	0	0
Min. turning radius (outer wheel)	mm	2100	2100	2100	2100
Power souce	V/kw	24/3	24/3	24/3	24/3
Runing speed (folding)	km/h	3.5	3.5	3.5	3.5
Runing speed (rising)	km/h	0.8	0.8	0.8	0.8
Rising/falling speed	sec	40/50	40/50	70/80	70/80
Battery	V/Ah	4x6/210	4x6/210	4x6/210	4x6/210
Charger	V/A	24/25	24/25	24/25	24/25
Max. climbing ability	%	20	20	20	20
Max. working allowable angle	°	2-3	2-3	2-3	2-3
Control type	/	Electro-hydraulic proportion control
Driver	/	Double front-wheel
Hydraulic drive	/	Double rear wheel
Wheelsize (stuffed & no mark)	/	381x127	381x127	381x127	381x127
Lifting capacity	kg	300	300	300	230
Lifting extend capacity		113	113	113	100
Whole weight	kg	1900	2080	2490	2760

3) Photos

4) workshop:

5) Warranty Policy and service program

SINOLIFT give our customer warranty in each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us we are always responsible for promotion our service.

Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.

If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.

SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items.
