Outdoor P10 Single Color LED Module, LED Sign, LED Billboard

Outdoor P10 Single Color LED Module, LED Sign, LED Billboard thumbnail-1
Outdoor P10 Single Color LED Module, LED Sign, LED Billboard photo-1
US$ 2 - 8 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Asram
Model Number:
P10 display module 32x10
Contact Supplier Request Quote Chat Now
Dongguan Asram Optoelectronic Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Asram
Model Number P10 display module 32x10
Usage Other, indoor,semi-outdoor, outdoor
Tube Chip Color Other, red, yellow, amber, white. blue, green
Display Function Other, text message pictures
Pixels Other, 7.625mm, 10mm, 12mm, 16mm, 20mm
Screen Dimension customized

Hot sale product:





P10 Red, Green, Blue, White, Yellow Color LED Display Module

Module  size(W/H)
320mm*160mm
Module  resolution(W/H)
32dots  x  16dots
Color available
red, yellow, blue, green, white
Density  of  pixel
10000dots/m²
Weight  with  cabinet
40kg/m²
Brightness in white color
5000cd/m²
Protection against water and dust
IP54(semi-outdoor) IP68(outdoor)
Hor.   Visible  angle
110°
Vert.   visible  angle
55°
Operating  Humidity
10~99%
Storage  Humidity
10~99%
Refresh  Rate
≥  400  Hz  with more  receiver card, higher refresh rate it has
Visible  Distance
≥ 10m  depends on the pixel pitch and the size of the display
Life  Time
100, 000  hrs
Max.   Power  Consumption
400W/m²
Certificates
CE, ROHS, CCC
Working  Voltage
220/110  VAC,   50/60  Hz
Drive  Method
1/4 scan or static is optional
Storage temperature
-20° C~65° C
Working temperature
-20° C~50° C  ; working under -30° C and  -40° C need special power supply and IC
Communication:
RS232, RS485, RS422, SD card, RJ45  for  option
Control system suggested:
Asynchronous:   CL2005, SCL2008, suppercom, Synchronism: Linsn801, T9  DBT-Q2007





Optional



Outdoor P10 Single Color LED Module, LED Sign, LED Billboard



Outdoor P10 Single Color LED Module, LED Sign, LED Billboard















Outdoor P10 Single Color LED Module, LED Sign, LED Billboard







Outdoor P10 Single Color LED Module, LED Sign, LED Billboard



















Outdoor P10 Single Color LED Module, LED Sign, LED BillboardOutdoor P10 Single Color LED Module, LED Sign, LED BillboardOutdoor P10 Single Color LED Module, LED Sign, LED BillboardOutdoor P10 Single Color LED Module, LED Sign, LED BillboardOutdoor P10 Single Color LED Module, LED Sign, LED Billboard





Outdoor P10 Single Color LED Module, LED Sign, LED Billboard







P10 LED single color module 320x160mm 1R/1G/1B/1Y



P12 LED single color module 400x200mm 2R/2G/2B/2T



P16 LED single color module 256x128mm 2R/2G/2B/2T



P20 LED single color module 320x160mm 2R/2G/2B/2T







P10 LED dual color module 320x160mm 1R1G/1B/1Y



P12 LED dual color module 192x192mm 2R1G/1B/1T



P16 LED dual color module 256x128mm 2R1G/1B/1T



P20 LED dual color module 320x160mm 2R1G/1B/1T







P10mm indoor/ourdoor led module(P12, P14, P16, P20, P25 is optional)



Color:  Red, Amber, Blue, White, Green



Size:  320X160mm, 32x16dots





CE  ROHS  UL  ISO  certification



OEM  ODM is acceptable
