Digital Watt Meter

Specifications

Digital Watt Meter For LED

asuring Amper

2.special for displaying
3.without deliverying output.
4.digital display

watt meter feature
1.analog output DC4-20mA.
2.built-in isolated CT, PT used for input signal.
3.display range 0-1999.
4.size 48H*96W.
parameter
function display special
peak load voltage 1.2×rated continous  1.5×rated 10 min; Ampere 1.2×
rated continous  1.5×rated 10 min
input mode CT.PT isolated
range  -0.5 to 1 to 0.5
measuring accuracy ±0.5%F.S
A/D converter  dual slope
sampling rate  about 2.5 times/ s
max. display   1999
effect of frequency vibration ≤ ±0.05%  45-65Hz.
display  LED light

withstand voltage strength  AC 1500V 1min.
insulation impedance  DC 500V ≥100MΩ.
power supply  AC 0~220V     50/ 60Hz

dimension 48H*96W*100D (mm) DIM
weight about 350g.

good quality and competitive price
