ACS Wire Electric Wire ASTM B415-1988
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HNTDDL
Model Number:
ACS wire
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Henan, China
Brand Name
HNTDDL
Model Number
ACS wire
Type
Bare
Application
Overhead
Conductor Material
Aluminum Clad Steel
Conductor Type
Stranded
Insulation Material
Other, Bare
Specifications
Aluminium-clad Steel Conductor normally used as OPGW,ground wire ,messenger wire, large quantities production.Specification
ACS Conductor manufacturer with ISO9001, ISO14001
ASTM B-415 Hard-Drawn Aluminum-Clad Steel Wire
ASTM B-416 Concentric-Lay-Stranded Aluminum-Clad Steel Conductors
Application
It is widely used in long-span transmission line, overhead ground conductor, extra high voltage overhead conductor, optical fiber composite overhead ground line, self-damping conductor line, etc.
ASTM B415-1998
ALUMINIUM CLAD STEEL WIRE
| Nominal Diameter | Area | Min. Tensile Strength | Calculated Breaking Load | Min. Coating Thickness | Max. D.C. Resistance at 20°c | Weight | |
| mm | AWG | mm² | mpa | kN | mm | Ω/km | kg/km |
| 2.052 | 12 | 3.307 | 1340 | 4.5 | 0.103 | 25.64 | 21.80 |
| 2.304 | 11 | 4.169 | 1340 | 5.6 | 0.115 | 20.34 | 27.49 |
| 2.589 | 10 | 5.260 | 1340 | 7.1 | 0.130 | 16.12 | 34.66 |
| 2.904 | 9 | 6.633 | 1340 | 8.9 | 0.145 | 12.78 | 43.65 |
| 3.264 | 8 | 8.367 | 1340 | 11.2 | 0.163 | 10.14 | 55.14 |
| 3.477 | 7 | 9.495 | 1310 | 12.4 | 0.174 | 8.93 | 62.57 |
| 3.665 | 7 | 10.55 | 1280 | 13.5 | 0.183 | 8.04 | 69.48 |
| 3.934 | 6 | 12.16 | 1240 | 15.1 | 0.197 | 6.93 | 80.13 |
| 4.115 | 6 | 13.30 | 1210 | 16.0 | 0.206 | 6.38 | 87.62 |
| 4.392 | 5 | 15.15 | 1170 | 17.7 | 0.220 | 5.60 | 99.84 |
| 4.620 | 5 | 16.76 | 1140 | 19.1 | 0.231 | 5.06 | 110.50 |
| 4.775 | 4 | 17.91 | 1100 | 19.7 | 0.239 | 4.73 | 118.0 |
| 5.189 | 4 | 21.15 | 1070 | 22.6 | 0.259 | 4.01 | 139.34 |
