Aluminium Clad Steel Strand DIN48201
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HNTDDL
Model Number:
ACS Strand
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PVC Insulation Power Cable for IEC DINNegotiableMOQ: 1 Kilometer -
Aluminium Clad Steel Wire/Strand ASTM B415,ASTM B416NegotiableMOQ: 1 Ton
-
PVC Insulted Wire for British SizesNegotiableMOQ: 500 Meters
-
PVC Insulated Electrical Wire--H03VH-H / Building WireNegotiableMOQ: 1 Kilometer
-
Alumoweld /Aluminium Clad Steel Strand ASTM B415, ASTM B416NegotiableMOQ: 1 Ton
Place of Origin
Henan, China
Brand Name
HNTDDL
Model Number
ACS Strand
Type
Bare
Application
Overhead
Conductor Material
Aluminum Clad Steel
Conductor Type
Stranded
Insulation Material
Other, Bare
Specifications
Aluminium-clad Steel Conductor normally used as OPGW,ground wire ,messenger wire,etc.Specification
ACS Conductor manufacturer with ISO9001, ISO14001
ASTM B-415 Hard-Drawn Aluminum-Clad Steel Wire
ASTM B-416 Concentric-Lay-Stranded Aluminum-Clad Steel Conductors
Application
It is widely used in long-span transmission line, overhead ground conductor, extra high voltage overhead conductor, optical fiber composite overhead ground line, self-damping conductor line, etc.
ASTM B415
ALUMINIUM CLAD STEEL WIRE
| Nominal Diameter | Area | Min. Tensile Strength | Calculated Breaking Load | Min. Coating Thickness | Max. D.C. Resistance at 20°c | Weight | |
| mm | AWG | mm² | mpa | kN | mm | Ω/km | kg/km |
| 2.052 | 12 | 3.307 | 1340 | 4.5 | 0.103 | 25.64 | 21.80 |
| 2.304 | 11 | 4.169 | 1340 | 5.6 | 0.115 | 20.34 | 27.49 |
| 2.589 | 10 | 5.260 | 1340 | 7.1 | 0.130 | 16.12 | 34.66 |
| 2.904 | 9 | 6.633 | 1340 | 8.9 | 0.145 | 12.78 | 43.65 |
| 3.264 | 8 | 8.367 | 1340 | 11.2 | 0.163 | 10.14 | 55.14 |
| 3.477 | 7 | 9.495 | 1310 | 12.4 | 0.174 | 8.93 | 62.57 |
| 3.665 | 7 | 10.55 | 1280 | 13.5 | 0.183 | 8.04 | 69.48 |
| 3.934 | 6 | 12.16 | 1240 | 15.1 | 0.197 | 6.93 | 80.13 |
| 4.115 | 6 | 13.30 | 1210 | 16.0 | 0.206 | 6.38 | 87.62 |
| 4.392 | 5 | 15.15 | 1170 | 17.7 | 0.220 | 5.60 | 99.84 |
| 4.620 | 5 | 16.76 | 1140 | 19.1 | 0.231 | 5.06 | 110.50 |
| 4.775 | 4 | 17.91 | 1100 | 19.7 | 0.239 | 4.73 | 118.0 |
| 5.189 | 4 | 21.15 | 1070 | 22.6 | 0.259 | 4.01 | 139.34 |
ASTM B 416
ALUMINIUM CLAD STEEL STRAND
| Code Number | Area | No. of wires | Diameter | Weight | Rated Strength | Max. D.C. Resistance at 20°c | |
| Wire | Cond. | ||||||
| mm2 | mm | mm | kg/km | kN | Ω/km | ||
| 3 No 5Awg. | 50.32 | 3 | 4.62 | 9.96 | 334.1 | 54.42 | 1.6990 |
| 3 No 6Awg. | 39.00 | 3 | 4.11 | 8.87 | 265.0 | 45.74 | 2.1420 |
| 3 No 7Awg. | 31.65 | 3 | 3.67 | 7.90 | 210.1 | 38.36 | 2.7010 |
| 3 No 8Awg. | 25.10 | 3 | 3.26 | 7.03 | 166.7 | 32.06 | 3.4060 |
| 3 No 9Awg. | 19.90 | 3 | 2.91 | 6.26 | 132.2 | 25.43 | 4.2940 |
| 3 No 10Awg. | 15.78 | 3 | 2.59 | 5.58 | 104.8 | 20.16 | 5.4150 |
| 7 No 5Awg. | 117.40 | 7 | 4.62 | 13.90 | 781.1 | 120.27 | 0.7426 |
| 7 No 6Awg. | 93.10 | 7 | 4.11 | 12.40 | 619.5 | 101.14 | 0.9198 |
| 7 No 7Awg. | 73.87 | 7 | 3.67 | 11.00 | 491.1 | 84.81 | 1.1600 |
| 7 No 8Awg. | 58.56 | 7 | 3.26 | 9.78 | 389.6 | 70.88 | 1.4630 |
| 7 No 9Awg. | 46.44 | 7 | 2.91 | 8.71 | 308.9 | 56.20 | 1.8440 |
| 7 No 10Awg. | 36.83 | 7 | 2.59 | 7.76 | 245.1 | 44.58 | 2.3250 |
| 7 No 11Awg. | 29.21 | 7 | 2.30 | 6.91 | 194.4 | 35.35 | 2.9320 |
| 7 No 12Awg. | 23.16 | 7 | 2.05 | 6.16 | 154.2 | 28.03 | 3.6970 |
| 19 No 5Awg. | 318.70 | 19 | 4.62 | 23.10 | 2129.0 | 326.39 | 0.2698 |
| 19 No 6Awg. | 252.70 | 19 | 4.11 | 20.60 | 1688.0 | 274.55 | 0.3402 |
| 19 No 7Awg. | 200.40 | 19 | 3.67 | 18.30 | 1339.0 | 230.18 | 0.4290 |
| 19 No 8Awg. | 158.90 | 19 | 3.26 | 16.30 | 1062.0 | 192.41 | 0.5409 |
| 19 No 9Awg. | 126.10 | 19 | 2.91 | 14.50 | 842.0 | 152.58 | 0.6821 |
| 19 No 10Awg. | 99.96 | 19 | 2.59 | 12.90 | 667.7 | 121.00 | 0.8601 |
DIN 48201
| Code Number | Area | No. of wires | Diameter | Weight | Rated Strength | Max. D.C. Resistance at 20°c | |
| Wire | Cond. | ||||||
| mm2 | mm | mm | kg/km | kN | Ω/km | ||
| 25 | 24.25 | 7 | 2.10 | 6.30 | 162.0 | 31.56 | 3.5460 |
| 35 | 34.36 | 7 | 2.50 | 7.50 | 229.0 | 44.72 | 2.4990 |
| 50 | 49.48 | 7 | 3.00 | 9.00 | 330.0 | 64.40 | 1.7360 |
| 70 | 65.81 | 19 | 2.10 | 10.5 | 441.0 | 85.65 | 1.3130 |
| 95 | 93.27 | 19 | 2.50 | 12.5 | 626.0 | 121.39 | 0.9250 |
| 120 | 116.99 | 19 | 2.80 | 14.0 | 785.0 | 152.26 | 0.7370 |
| 150 | 147.11 | 37 | 2.25 | 15.7 | 990.0 | 191.46 | 0.5870 |
| 185 | 181.62 | 37 | 2.50 | 17.5 | 1221.0 | 236.38 | 0.4760 |
| 240 | 242.54 | 61 | 2.25 | 20.2 | 1635.0 | 299.05 | 0.3570 |
| 300 | 299.43 | 61 | 2.50 | 22.5 | 2017.0 | 369.20 | 0.2890 |
