Baby Diaper Making Machine JWC LKB

Specifications

Main Technical Parameters:

1. Type: JWC-LKB

2. Designed speed: 80m/min

3. Practical speed: 100-150pcs/min

4. Installed capacity: 80KW(380V 50HZ)

5. Practical capacity: 70KW(380V 50HZ)Breaker : 250A

6. Machine size: 20×3.2×3M (L×W×H)

7. Working size: 24×6×4M (L×W×H)

8. Total weight: 18T

9. Air compressor: 1m³/min  more than 0.6Mpa

10. Product size:( L×W) (to be adjusted)

S: 380×270mm     M: 450×310mm

L: 515×330mm     ×L: 540×340 mm

11. container: 1×40HQ+1×20GP

Main functions and features:

1. The fluff adopts aggregate pulp feeding unit or forming drum feeding system. It can produce diapers of economic type. It can produce four types of products (XL, L, M, S) with only few parts changed.

2. The machine can produce I-shape or T-shape diapers which according to the customer’s samples. .

3. The machine has top sheet non woven , back sheet Pe film ,frontal tape and side tape devices.

4. Both sides with leak proof cuffs. Material for stereo shield is cut and shaped by hot press on the equipment. It adheres to elastic ribbon to be formed for side leakage proof.

5. After the side arcs are shaped, the wings will be tri-folded lengthwise. The diaper pads will be output in line and easy for packing.

Options:

1. Elastic waistband unit

2. Acquisition Layer unit.
