0.6 Inch 7 Segment Led Display, Red Color 1 Digit

Name: 0.6 Inch 7 Segment Led Display, Red Color 1 Digit
Brand: ATI-0.6 inch 7 segment
SKU: 132235525
Availability: InStock

ATI Electronics Technology Limited (Wuxi)

US$ 0.09 - 0.1 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

ATI-0.6 inch 7 segment

Model Number:

SM420601N

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name ATI-0.6 inch 7 segment

Model Number SM420601N

Usage Indoor

Tube Chip Color Other, Red color

Display Function Graphics

Pixels Other, 1MM

Screen Dimension 18 x 25 x 8.3mm

ATI 0.6 inch 7 segment LED DISPLAY

Features—Our Products Stand out of Others

1.Over 12 years producing experience as the vendor of Samsung,A.O Smith, Haier,LG etc.

2.Big scale of producing makes sure that your purchase cost is lower.

3.Advanced production line guarantees stable quality and long life span.

4.High luminous intensity output, low voltage and current operating, ultra-low power consumption.

5.Solid-state LED Epistar chip based, easy mounting on printed circuit board and sockets.

Product Exhibition—Show the Details for You

ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:

PARAMETER	SYMBOL	TEST CONDITION	Color	MIN	TYP	MAX	UNIT
Forward Voltage ,Per Segment	VF	IF=20mA	Red	1.9	2.0	2.5	V
Reverse Current , Per Segment	IR	VR=5V	Red			50	μA
Peak Emission Wavelength	λp	IF=20mA	Red	630	633	637	nm
Luminous Intensity Per Segment	IV	IF=20mA	Red	30	35	50	mcd
