0.56" 2 digit led number display green color 7 segment led display

FOB Price

USD $0.139 - $0.239 / Piece

1000 Pieces(Min.Order)

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	ATI	Usage:	Indoor
Tube Chip Color:	Green	Display Function:	Graphics	Screen Dimension:	25.0x 19.0 x 8.0mm

ATI 7 SEGMENT LED NUMBER DISPLAY

Features—Our Products Stand out of Others

1.Over 12 years producing experience as the vendor of Samsung,Haier,LG etc.

2.Big scale of producing makes sure that your purchase cost is lower.

3.Advanced production line guarantees stable quality and long life span.

4.High luminous intensity output, low voltage and current operating, ultra-low power consumption.

5.Solid-state LED Epistar chip based, easy mounting on printed circuit board and sockets.

Product Exhibition—Show the Details for You

ELECTRICAL/OPTICAL CHARACTERISTICS AT Ta=25°C:

PARAMETER	SYMBOL	TEST CONDITION	Color	MIN	TYP	MAX	UNIT
Forward Voltage ,Per Segment	VF	IF=20mA	y/green	2.0	2.2	2.5	V
Reverse Current , Per Segment	IR	VR=5V	y/green			50	μA
Peak Emission Wavelength	λp	IF=20mA	y/green	570	571	573	nm
Luminous Intensity Per Segment	IV	IF=20mA	y/green	35	38	40	mcd

Perfect Product Package—We Care about Your Goods and You

Our New Production Line—Make Your Choice to be The Best

Our Certifications—No Worry for Our Products

7 segment LED Display Series—More Choices for Your Purchase
