Construction scaffolding panel roll forming machine manufacturer
Working flow:
Decoiler------guiding------leveling------roll forming-------punching-----cut to length-----output table
Machine components:
No. |
Name |
Qty |
1. |
De-coiler |
1 Set |
2. |
Roll Forming Machine |
1 Set |
3. |
Hydraulic Cutting Device |
1 Set |
4. |
PLC Control Box |
1 Set |
5. |
Output table |
1 Set |
Technique parameters of the processing line
(1) Plate Material: Galvanized plate/strip steel
(2) Thickness of the plate : 1.5-2mm(different thickness is ok)
(3) Machine body :350mm H steel
(3) Wall thickness of the main forming machine: 18mm steel plate
(4) Outside debugging to change sizes
(5) Transmission chain : 2’’
(7) Reducer :15kw Xingxing Cycloid which works stably and no noise.
(8) Seam type semi-mat
(9) Roller material: GCr15 with quenched treatment 62-64°C
(10) Rollers14 steps including 9 shafts for leveling.
(11) 4 steps side wheels on the coil-input part for avoiding coil-deviation
(12) Forming part adopts side wheel rotation forming to reduce friction between rollers and coil. Easy and fast debugging
(13) Diameter of active shaft: 80mm, 45# steel
(14) Hydraulic pump power: 7.5KW
(15) PLC control system with inverter
(16) Working Speed: 8-12m/min
Detailed photos:
Guarantee period: one year free service/ pay service all the machine life
Installation and training:
If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
Without visiting,we will send you user manual and CD to teach you to install and operate.
If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
Cangzhou Best machinery mannufacturing Co,.ltd the most advantage: specilized in making special cold roll forming machines, we can make machines according to your special profile drawings.
