Flat Type CNC Lathe Machine CKI6140
PRODUCT FEATURES
- Machine body guide way are quenched for better resistance of abrasion,and increased stability and accuracy.
- 6136,6140 machine employ intergrated body structure,and extra wide guide way with better vibration resistance.
- Spindle,saddle adopt special structure and technology,which increase precision,stability and accuracy.
- Models above 6150 adopt gear box transmission design,and are equipped with inverter spindle motor which can enable strong cutting force with 3-level gear speed,and change rotation speed by controller system at each speed level.
- Optional control system:GSK Control System,KND Control System and Fanuc Mate Control System.
Specification: CNC Lathe Machine CKI6140
| Model | CKI6140 | |
| Max swing diameter over table | mm | 420 |
| Max swing diameter over carriage | mm | 230 |
| Max length of workpiece | mm | 750 |
| Width of guide rail | mm | 340 |
| Model of chuck | K11/200 | |
| Spindle rotation speed | rpm | 2800 |
| Variable structure of spindle box | Variable speed | |
| Spindle motor | kw | 5.5 |
| Spindle head and spindle taper | Metric80/A2-6 | |
| Diameter of spindle hose | mm | Φ70 |
| Max moving speed of X axis | m/min | 6 |
| Max moving speed of Z axis | m/min | 8 |
| Diameter of sleeve | mm | Φ65 |
| Travel of sleeve | mm | 120 |
| Taper of tailstock sleeve | MT4 | |
| Positioning accuracy | mm | 0.01 |
| Dimension(L*W*H) | mm | 2385×1200×1800 |
| Net weight | kg | 1600 |
| Top distance | mm | 750 |
Accessories
1.Standard Accessories
Four position electronic turret
3-jaw chuck
Tool and toolbox
2.Optional Accessories
Six position electronic turret
Hydraulic tailstock
Fanuc controller
After-sales services
Warranty is a year, we would offer the parts( quality problem) free of charge during this period. Overseas service need to be charged extra.
Plant
Our company builds modern production lines:CNC Milling Machine production line,Vertical Machine Center production line,Gantry Type Machine Center production line,Milling Machine production line,Surface Grinding Machine production line,EDM production line etc.
Research and Development team
We have a large group of Research and Development team , they own the professional theory knowledge, special technology skills and rich experience in the technical research field.
Certificate and Honour
- 8 Intellectual property rights and 5 the patents
- The self-owned brands of JOINT,NC-JYD have become the famous and high-quality mark in Chinese machinery field.
- From 2004 to 2007,we have been granted with “Top 100 Metal Cutting Machine Tool Manufacturers” in China.
- In 2011,we have been granted as "National Grade HI-Tech Enterprise".
- We have introduced ISO9001:2008 in 2009.
- The turret Vertical milling machine,NC knee type milling machine and Vertical machine center and Surface grinding machine has obtained CE certificate notified by CCQS.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-15days if the goods are in stock. or it is 10-15 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: 30% in advance.and the rest payment should pay before delivery.
Q: How many years have your company established?
A: 20 years, our company built in 1995.
