WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45

WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 thumbnail-1
WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 photo-1
US$ 18 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DONGWE
Model Number:
DW-T1000G
Contact Supplier Request Quote Chat Now
Shenzhen Dongwe Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DONGWE
Model Number DW-T1000G

WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45



Product Description



Features of WS-G5483 GBIC

  • Hot-pluggable GBIC footprint
  • Extended case temperature range (0°C to +70°C )
  • Low power dissipation (1.05 W typical)
  • Compact RJ-45 connector assembly
  • Access to physical layer IC via 2-wire serial bus
  • 1000 BASE-T operation in host systems with SERDES interface



Applications of WS-G5483 GBIC

  • 1.25 Gigabit Ethernet over Cat 5 cable



Product Description of WS-G5483 GBIC

DW-T1000G 1000BASE-T Copper GBIC transceivers are based on the GBIC Multi Source Agreement
(MSA). They are compatible with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE Std
802.32. The 1000BASE-T physical layer IC (PHY) can be accessed via I2C, allowing access to all PHY
settings and features. The DW-T1000G uses the GBIC’s RX_LOS pin for link indication, and 1000BASE-X
auto-negotiation should be disabled on the host system. The DW-T1000G is compatible with 1000BASE-X
auto-negotiation, but does not have a link indication feature(RX_LOS is internally grounded).



Ordering Information
Part Number Product Description
DW-T1000G Copper GBIC, 1.25G, RJ45, 0°C~+70°C
DW-D1285-05CG GBIC, 1.25G, 850nm, 550m, 0°C~+70°C
DW-D1231-20CG GBIC, 1.25G, 1310nm, 20km, 0°C~+70°C
DW-D1231-40CG GBIC, 1.25G, 1310nm, 40km, 0°C~+70°C
DW-D1255-80CG GBIC, 1.25G, 1550nm, 80km, 0°C~+70°C

BIDI GBIC
DW-S1235-03CG BIDI GBIC, 1.25G, 1310/1550nm, 3km,  0°C~+70°C
DW-S1253-03CG BIDI GBIC, 1.25G, 1550/1310nm, 3km,  0°C~+70°C

DW-S1234-20CG BIDI GBIC, 1.25G, 1310/1490nm, 20km,  0°C~+70°C
DW-S1243-20CG BIDI GBIC, 1.25G, 1490/1310nm, 20km,  0°C~+70°C
DW-S1235-20CG BIDI GBIC, 1.25G, 1310/1550nm, 20km,  0°C~+70°C
DW-S1253-20CG BIDI GBIC, 1.25G, 1550/1310nm, 20km,  0°C~+70°C

DW-S1234-40CG BIDI GBIC, 1.25G, 1310/1490nm, 40km,  0°C~+70°C
DW-S1243-40CG BIDI GBIC, 1.25G, 1490/1310nm, 40km,  0°C~+70°C
DW-S1235-40CG BIDI GBIC, 1.25G, 1310/1550nm, 40km,  0°C~+70°C
DW-S1253-40CG BIDI GBIC, 1.25G, 1550/1310nm, 40km,  0°C~+70°C

CWDM GBIC

DW-D12CXX-40CG

(XX=27~61)

 CWDM GBIC, 1.25G, 1270~1610nm, 40km, 0°C~+70°C


DW-D12CXX-80CG

(XX=27~61)

 CWDM GBIC, 1.25G, 1270~1610nm, 80km, 0°C~+70°C



Compatible Brands

WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45



Product Serial
WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45
WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45
WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45 WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45












Package and shipment

WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45

Shipment:

International  Express: DHL, FedEx, UPS, TNT and EMS optional

Factory Show

WS-G5483, 1000BASE-T Copper GBIC, 1.25G, RJ45

Our Service

      1.  Competitive price

      2.  3 years warranty
        3.  Reply your inquiry within 2 hours
      4.  Have large quantity modules in stock, delivery fast
      5.  Label can be customized, also ODM and OEM service offered
      6.  100% new material and good quality
      7.  Can be compatible with a lot of brands like Cisco, HP, H3C, Extreme, Juniper etc.
      8.  Capacity: 10,000pcs/day
      9.  Certificates below:
