SC Connector GBIC Transceiver 1000BASE-SX 1.25G 850nm 550m WS-G5484
Features of SC Connector GBIC Transceiver
¨ Dual data-rate of 1.25Gbps/1.0625Gbps operation
¨ 850nm VCSEL laser and PIN photodetector
¨ Duplex SC optical interface
¨ Standard serial ID information compatible with SFF-8053
¨ 550m transmission with 50/125 µm MMF
¨ 275m transmission with 62.5/125 µm MMF
¨ +3.3V/5V single power supply
¨ RoHS Compliant
¨ Operating case temperature: 0 to +70℃
Applications of SC Connector GBIC Transceiver
¨ Switch to Switch interface
¨ Switched backplane applications
¨ Router/Server interface
¨ Other optical transmission systems
Product description of SC Connector GBIC Transceiver
The GBIC transceiver is high performance, cost effective module supporting dual data-rate of 1.25Gbps/1.0625Gbps 1.25Gbps/1.0625Gbps and from 500m transmission on 50/125 µm MMF.
The transceiver consists of two sections: The transmitter section incorporates a VSCEL laser. And the receiver section consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA). All odules satisfy class I laser safety requirements.
The optical output can be disabled by a TTL logic high-level input of Tx Disable. Tx Fault is provided to indicate degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver.
The standard serial ID information Compatible with GBIC MSA describes the transceiver’s capabilities, standard interfaces, manufacturer and other information. The host equipment can access this information via the two-wire serial CMOS EEPROM protocol. For further information, please refer to SFF-8053.
| Part Number | Product Description |
| DW-T1000G | Copper GBIC, 1.25G, RJ45, 0°C~+70°C |
| DW-D1285-05CG | GBIC, 1.25G, 850nm, 550m, 0°C~+70°C |
| DW-D1231-20CG | GBIC, 1.25G, 1310nm, 20km, 0°C~+70°C |
| DW-D1231-40CG | GBIC, 1.25G, 1310nm, 40km, 0°C~+70°C |
| DW-D1255-80CG | GBIC, 1.25G, 1550nm, 80km, 0°C~+70°C |
| BIDI GBIC | |
| DW-S1235-03CG | BIDI GBIC, 1.25G, 1310/1550nm, 3km, 0°C~+70°C |
| DW-S1253-03CG | BIDI GBIC, 1.25G, 1550/1310nm, 3km, 0°C~+70°C |
| DW-S1234-20CG | BIDI GBIC, 1.25G, 1310/1490nm, 20km, 0°C~+70°C |
| DW-S1243-20CG | BIDI GBIC, 1.25G, 1490/1310nm, 20km, 0°C~+70°C |
| DW-S1235-20CG | BIDI GBIC, 1.25G, 1310/1550nm, 20km, 0°C~+70°C |
| DW-S1253-20CG | BIDI GBIC, 1.25G, 1550/1310nm, 20km, 0°C~+70°C |
| DW-S1234-40CG | BIDI GBIC, 1.25G, 1310/1490nm, 40km, 0°C~+70°C |
| DW-S1243-40CG | BIDI GBIC, 1.25G, 1490/1310nm, 40km, 0°C~+70°C |
| DW-S1235-40CG | BIDI GBIC, 1.25G, 1310/1550nm, 40km, 0°C~+70°C |
| DW-S1253-40CG | BIDI GBIC, 1.25G, 1550/1310nm, 40km, 0°C~+70°C |
| CWDM GBIC | |
|
DW-D12CXX-40CG (XX=27~61) |
CWDM GBIC, 1.25G, 1270~1610nm, 40km, 0°C~+70°C |
|
DW-D12CXX-80CG (XX=27~61) |
CWDM GBIC, 1.25G, 1270~1610nm, 80km, 0°C~+70°C |
|
|
|
|
|---|---|---|---|
|
|
|
|
|
|
|
|
Shipment:
International Express: DHL, FedEx, UPS, TNT and EMS optional
1. Competitive price
You may also be interested in other products like:
WS-G5483 WS-G5484 WS-G5486 WS-G5487
GLC-T GLC-SX-MM GLC-LH-SM GLC-EX-SM
GLC-ZX-SM GLC-BX-D GLC-BX-U
SFP-10G-SR SFP-10G-LR SFP-10G-ER SFP-10G-ZR
For further information and more products, please don't hesitate to contact us, we would be glad to hear from you. Thanks!!! :) :) :)
