24 port full giga switch with 2 SFP optical fiber ports samll metal housing
Introduction
SW2624G supply 2SFP ports and 24 port TX 10/10/1000Mbps fiber switch. This device comes with SFP port, easy for optical fiber remote transmission.
Main Features
2SFP+24FE, with different modules, can up to 100KM.
Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab.
Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.
Auto MDI/MDIX.
Upstream port lightning protection.
Store-and-forward.
All ports support wire speed switch, jumbo frame transmission.
Zero QFD, self-adaption.
Panel lights can monitor operative mode and malfunction analysis.
Specification
Model |
SW2624G |
|
Electric Port |
100M Rj45 |
24 |
SFP |
2 |
|
|
Function |
Exchange Mechanism |
Store-and-forward |
Exchange Capacity |
12.8G |
|
MAC |
8K |
|
|
Environmental |
Working Temperature:0℃~40℃ Storage temperature :-40℃~70℃ |
|
|
Working Humidity :10%~90% RH non-condensing Storage Humidity:5%~90% RH non-condensing | ||
power |
DC12V 2A AC 110-220V 50/60HZ |
|
|
Network protocol |
IEEE 802.3X IEEE 802.3i 10BASE-T X IEEE 802.3u 100BASE-TX IEEE 802.3z 1000BASE-X G IEEE 802.3x Flow control IEEE 802.1q VLAN Bridge operation |
|
|
Default Mode |
Common switch |
|
Match |
VLAN isolation |
|
Speed |
Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex |
|
|
Network Media |
10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000Base-SX:62.5μm/50μm MMF(2m~550m) 1000Base-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) |
|
Physical Specifications |
Product Size:285mm*220mm*45mm(L*W*H) package Size:410mm*280mm*95mm(L*W*H) 2kg |
|
Product Ordering Information :
Model Number:SW2624G
Product Details:2SFP+24GE
