Specifications
Q48series Hanging type shot blasterShot cleaning
Surface Finishing
High efficiency
Large productivity
Company indroduction:
Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..
Products Detail:
Q48series Hanging type shot blaster
Overhead hanger chain type sand shot cleaning machine for automobiles, tractors ,motors and other small and medium-sized enterprises of Casing and Forging, sheet metal piece to strengthen the surface and clean-up or treatment; also suitable for liquefied gas bottles clean up the surface rust transmission line, the series of products with the continuity of good,clean-up efficient and canbe use in the line.
Overhead hanger chain type sand shot cleaning machine The workpieces are carried on rotating hooks on the Manually operated monorail to the blast cabinet where they are blasted by blast wheels. The blast cycle runs in accordance with the preset blast time. When the blast wheels stop, the door is opened and the hook exits automatically.
Surface treatment of parts produced by casting, die-casting, forging, drop-forging, or heat-treated.
Q48series Hanging type shot blaster technical parameter:
MODEL |
Q483 |
Q485 |
Q4810 |
ITEM | |||
Productivity (hook/h) |
10 |
10 |
10 |
Conveying Speed (m/min) |
2.44 |
7.34 |
2.44 |
Workpiece Maximum Weight (Kg) |
300 |
500 |
800 |
Distance between Hooks (mm) |
2560 |
2560 |
2560 |
Abrasive Flow Rate (Kg/min) |
250*2 |
250*3 |
360*6 |
Ventilation Capacity (m/3h) |
6000 |
10000 |
25000 |
Workpiece Maximum Dimension (mm) |
φ 1000*1400 |
φ 1200*1700 |
φ 700*2400 |
Total Power (Kw) |
38.75 |
58.43 |
85 |
Overrall Dimension (mm) |
8450*5350*5003 |
12235*5410*9411 |
4500*5350*5003 |
Q48series Hanging type shot blaster picture:
Q48series Hanging type shot blaster picture:
Q48series Hanging type shot blaster machine picture:
SPARE PARTS:
