Specifications
Q31 series Small Rolling Drum Shot Blasting Machine1.direct supplier
2.small rolling drum
3.high efficiency
4.ISO900
Company indroduction:
Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..
Products Detail:
Q31 series Small Rolling Drum Shot Blasting Machine
Small Rolling Drum Shot Blasting Machine is designed for Shot Blast Cleaning of small or medium size iron, steel, alloy and non-ferrous castings, forgings, heat treated parts. The main parts of Small Drum Shot Blasting Machine as follows:
Rolling Drum Shot Blasting Machine is suitable for surface rust removal of work pieces in medium or small quantity batch production with many varieties. Put the work pieces into the barrel and blasting it in side way.
The high-speed impeller throws the abrasive to the continuous tumbling castings or forgings in barrel, to remove the greensand or scales on the surface. It cleans evenly and its productivity is high, so it is suitable for cleaning the small work pieces whose weight are under 15g in medium or small-scale casting or forging workshops.
Q31 series Rolling Drum Shot Blasting Machine is our popular model, we have shipped to many countries, Asia market, south American market, Canada, Europe market and so on.
Q31 seriesRolling Drum Shot Blasting Machine can be customized as clients’ request.
Rolling drum shot blasting machine parameter:
Item |
Q3110 |
Q3110A |
Q3113 |
Q3113A |
Diameter of rolling drum(mm) |
1000 |
1000 |
1300 |
1300 |
Loading capacity(kg) |
300 |
300 |
600 |
600 |
Productivity(kg/h) |
600-1500 |
600-1500 |
2500-3500 |
2500-3500 |
Power(excluding dust collector) (kw) |
9.7 |
11.9 |
14.5 |
16.3 |
Max weight of workpiece(Kg) |
15 |
15 |
30 |
30 |
Speed of rolling drum(r/min) |
3 |
3 |
2.5 |
2.5 |
Abrasive flow rate(kg/min) |
120 |
120 |
160 |
160 |
Ventilation capacity(M3/h) |
800 |
2000 |
2000 |
2800 |
Q31 series Rolling drum shot blasting machine picture:
