Specifications
Sand blasting machineOEM
High quality
Competitive price
large productivity
Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment ,, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..
Products Detail:
Sand peening/blasting Machine
simple operation, convenient maintenance and low cost
necessary tool for traditonal corrosion resistance operation, such as marine repair, rust removal of piping and tank body,renewal of container etc.
be suitable for connection to SSCE pneumatic or electro-pneumatic remote control systems and pneumatic remote control system with air blast and blow function
be available on request as stationary units, as well as sikd based units
Sand blasting machine technology parameter:
Technology Parameter of portable sandblaster | |||||
Item Type |
Q0250 |
Q0250-II |
Q0250-II-LX |
||
Volume of in-tank (m3) |
0.5 |
0.67 |
0.8 |
||
Diameter of compressed air pipe |
11/2” |
11/2” |
11/2” |
||
Air pressure (Mpa) |
0.5-0.6 |
0.5-0.6 |
0.5-0.6 |
||
Emitted dose (bore Φ10)(kg/h) |
1800-2200 |
1pc gun |
1800-2200 |
1pc gun |
1800-2200 |
2pcs gun |
3600-4400 |
2pcs gun |
3600-4400 |
||
Air consumption (m3/min) |
6.1 |
1pc gun |
6.1 |
1pc gun |
6.1 |
2pcs gun |
12.2 |
2pcs gun |
12.2 |
||
Control motion |
Remote controlled (This installation should be illustrated in the order) |
||||
Length of sand blasting pipe (mm) |
7000 |
7000 (2pcs) |
7000 (2pcs) |
||
Dimension (mm) |
1036*812*1860 |
1120*900*1890 |
1086*812*2060 |
||
Weigh (kg) |
396 |
500 |
690 |
||
Sand blasting machine picture:
