Casting core making machine/ZH8060 sand shoot core machine for foundry

Specifications

Casting core making machineZH8060 sand shoot core machine
PLC control
Adjustable technics parameters

Company indroduction:

 Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..



 Products  Detail:

Casting core making machine:ZH8060 sand shoot core machine for foundry / core shooting machine

 Core making  processes simple,easy to operate.the advantage as follow:

1:core shooter machine adopt special design, no big bottom-closing-force during sand shooting, no shock and big force to machine   frame.

2: Quick and convenient sand cleaning system for shooting head, shooting

3: plate, sand shooting nozzel.

4: Quick hydraulic metal mould change system.

5: Advanced and powerful low-pressure sand shooting device.

6: Top and bottom core ejection system. Pre-press quick core stripping, small damage, no core-repairing

7: Outer-machine-core-picking, stable core ejection, convenient for core-picking.

8: Gas generator adopt magnetic pump, high guaging precision, long service life time.



Casting core making machine ZH8060 sand shoot core machine for foundry as follows:

Item	ZH8060
Molding plate size(mm)	800*700
Molding  thick(mm)	400-600
Maximum sand core weight(kg)	40
Sand copper capacity(kg)	200
Heating power(kw)	45
Control	Pneumatic/hydraulic
Pneumatic system(Mpa)	0.58
Operation mode	Semi-automatic/automatic



Casting core making machine/ZH8060 shoot core machine picture as follows:
