Help CenterSYD-0193 Automatic Lubricating Oils Oxidation Stability Tester
Related Products
-
SYD-507 Insulating Oils Breakdown Voltage TesterUS$ 3,835 - 4,260MOQ: 1 Piece -
SYD-265H Intelligent Kinematic ViscometerUS$ 3,085 - 3,425MOQ: 1 Piece
-
SYD-265G Low-temperature Kinematic ViscometerUS$ 5,000 - 5,555MOQ: 1 Piece
-
SYD-265H-2 Automatic Kinematic ViscometerUS$ 6,335 - 7,040MOQ: 1 Piece
-
SYD-3536A Automatic Cleveland Open Cup Flash Point TesterUS$ 4,750 - 5,280MOQ: 1 Piece
The instrument is designed and made as per industrial standard of People’s Republic of China SH/T 0193 Lubricating oils-Determination of oxidation stability-Rotating pressure vessel methodand ASTM D2272 Standard test Method for Oxidation Stability of Steam Turbine Oils by Rotating Pressure Vessel.
The instrument is used to determine the oxidation stability of steam turbine with the same composition (oil base oil and additive) .Also can be used to determine new mineral insulating oil containing 2,6-BHT.
I. Main technical features
1. This instrument is fully designed as per standard SH/T0193. It can automatically determine pressure, record data, calculate oxidation time and finish the determination.
2. The test procedures can be done automatically. No need for human interference. The test precision is high.
3. The test curves and results will be shown on the screen and can be restored and printed if needed.
II. Main technical specifications
1.Power supply: AC220V±10%
2.Heating tube power: 2500W
3.Range for pressure sensor: (0~1.6)MPa,accuracy:±2‰
4.Temperature controll range for oil bath: Room temperature~200.0℃, continuously adjustable.150.0℃ in common use.
5.Temperature control accuracy: ±0.1℃
6.Test sample:Two-bomb design, can do two samples at one time. Convenient to do parallel test.
7. Rotation speed: (100±5)r/min
8. Included angle between oxygen bomb and water level: 30°
9. Volume of oil bath: 30L
10.Dimension: 550mm×800mm×1000mm
11.Net weight: About 45Kg
