Help Centerv Guide Rubber Conveyor Belt
Related Products
-
Chevron Pattern Rubber Conveyor BeltUS$ 30 - 120MOQ: 100 Meters -
High Quality Chevron Conveyor BeltUS$ 30 - 120MOQ: 50 Meters
-
20-45degree Chevron Conveyor BeltUS$ 30 - 120MOQ: 30 Meters
-
Pattern Conveyor BeltUS$ 30 - 120MOQ: 30 Meters
-
Big Angle Patterned Rubber Conveyor BeltsUS$ 30 - 120MOQ: 100 Meters
Specifications
v guide rubber conveyor belt1Color: black
2Working slope:20-45degree
3Cover Rubber:9-25mpa
ISO9001:2008
v guide rubber conveyor belt
Application
In order to improve the delivery angle, prevent the material down, the cover rubber of the conveyor belt can be made of pattern designs.
Classified
Pattern conveyor belt is composed of belt carcass and pattern. Pattern shape and height(depth) may be different because of different conveyor material and gradient of conveyor.
Shallow pattern conveyor belt (pattern thickness below 10mm, delivery angle:20°~30°)
Deep pattern conveyor belt (pattern thickness above 10mm, delivery angle:30°~45°)
Pattern design form
Chevron shape, cleat shape, cylinder pattern.
Superiority
V type:The tip angle of the V pattern type is on the central line which makes the carried materials can be collected to the center
Circularity type: (Round pit type)
The circularity type can make the handling material to the central part of the collection
Other related products
| No. | Rubber Conveyor Belt | Code |
| 1 | Sidewall Conveyor Belt | MSTB/S |
| 2 | Conveyor Belt for General Purpose | MSTB/P |
| 2.1 | EP Conveyor Belt | MSTB/EP |
| 2.2 | Nylon Conveyor Belt | MSTB/NN |
| 2.3 | Cotton Conveyor Belt | MSTB/CC |
| 2.4 | Steel Cord Conveyor Belt | MSTB/ST |
| 3 | Conveyor Belt for Specific Purpose | MSTB/SP |
| 3.1 | Heat Resistant Conveyor Belt | MSTB/HR |
| 3.2 | Fire Retardant Conveyor Belt | MSTB/FR |
| 3.3 | Cold Resistant Conveyor Belt | MSTB/CR |
| 3.4 | Oil Resistant Conveyor Belt | MSTB/OR |
| 3.5 | Chemical Resistant Conveyor Belt | MSTB/CHR |
| 4 | Chevron Conveyor Belt | MSTB/V |
| 5 | Elevator Conveyor Belt | MSTB/E |
| 6 | PVC/PU Conveyor Belt | MSTPVCB |
| 7 | V Belt | MSTVB |
Production Processing
Inquiry List | ||
Belt width |
mm |
|
Fabric |
||
Ply |
mm |
|
Top and bottom rubber thickness |
Mpa |
|
Tensile strength of cover rubber |
m |
|
Belt length |
||
Transport material |
||
Material size |
mm |
|
Material temperature |
Degree |
|
