Home > Products > Hydraulic Pressure Block Making Machine > QT4-15 fully automatic concrete block making machine
QT4-15 fully automatic concrete block making machine
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Condition: | New | Type: | Other, Hollow.Solid,Paving,Interlocking block making machine | Brick Raw Material: | Concrete |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | fully automatic concrete block making machine make 3800~4500/h | Place of Origin: | Shandong, China | Brand Name: | Huali fully automatic concrete block making machine |
Model Number: | QT4-15 fully automatic concrete block making machine | Voltage: | 220V/380V/440V | Power: | 24kw |
Dimension(L*W*H): | 3000*2200*2600 | Certification: | ISO9001/BV | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Christmas sales promotion qt4-15 fully automatic concrete block making machine
Overall Dimension | 3000×2200×2600 mm |
Rated Pressure | 7.5-14MPa |
Main Vibration Form | Plant-form Vibration |
Cycle Time | 15 Seconds |
Vibrating Frequency | 2850 rolls/minute |
Vibration Force | 60KN |
Overall Weight | 8.5T |
Motors Power | 24KW |
Raw Materials | fully automatic concrete block making machine crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes |
Applied Products | fully automatic concrete block making machine make Hollow block, Solid Block and Paver,interlocking blocks. |
Capacity/Productivity:
SIZE(L*W*H) | CYCLING TIME/S | PCS/MOULD | PCS/HOUR | PCS/Day |
390*190*190 | 15S | 4 | 640~720 | 6400~7200 |
240*115*90 | 15S | 14 | 1900~2250 | 19000~22500 |
240*115*53 | 15S | 26 | 3800~4500 | 38000~45000 |
200*100*60 | 15s | 16 | 2880~3360 | 23040~26880 |
Brief Introduction:
1.fully automatic concrete block making machine adopt the frequency conversion control,so all its speeds and pressures can be adjustable.So the operation running of the machine is smooth and steady;reduce the impacts and noises;and increased the equipment stability.
2.fully automatic concrete block making machine main sections and parts are treated by carburizing so that they are sturdy and wear resisting,and the cost in vulnerable parts are decreased.
3.Import main parts of electrical appliances and hydraulic system,so service life has been increased.
4.The trouble Warning System:Displaying the guidance and indications in maintenance and in trouble-shooting in time,in order to avoid any unnecessary losses.
Main Raw Materials:
1. Area: Workshop area:200-300m2, all factory area 1500m2, the bigger, the better.
2. Workers : 4 or 5 workers.
3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,
about cement :sand : stone is1:4:5.
4. Hollow block weight:
(400*200*200) :17KG,(400*150*200):13.5KG,(400*100*200):10KG
5. Hollow blocks can reach 8-10Mpa,Solid bricks can reach 10-12Mpa,Pavers and
Interlocking bricks can reach 12-15Mpa,so they have a higt pressure,can be widely used.
Block Sample:
Application:
fully automatic concrete block making machine make grass land blocks series, application examples for porous concrete block (as shown in the pictures)
Successful cases:
You are always welcomed to visit our company and workshop!
Terms & Conditions:
1) 1. FAST SHIPPING from our Linyi China Factory!
2. Delivery time: 15-20 working days after receive deposit.
3. Shipping Cost: Depending on the fully automatic concrete block making machine size and weight of total order.
4. Accept the FOB/CIF/CNF terms of trade.
5. B/L will be sent to you as soon as after delivery.
2) Payment Term: 30% deposit,70% balance by T/T, Western Union or Money-Gram etc.
Warranty Period: One year after installation finished at buyer's factory.
As a professional exporter,our target is to serve worldwide clients with high-quality products,greatreliability,devoted responsibility,professional services and honorable credibility to meet customers' requirements in all aspects. We will supply you 24 hours a day and 7 days a week after-sale services.
A:1) Competitive price(direct manufacturer)
2) Can design different brick/block mould according to your size.
3) Our machine use strongth hight-strength steel structure,block mould all by heat treatment.
can use thirty million times.
4) Great after sales service!
Producing VIdeo on YouTube: /watch?v=gO2QyCH753g
Linyi Huali Machinery Co.,Ltd
Block Machine Making,Selling,Marketing&Service
Mob/WhatsApp/Viber/WeChat:0086-13407665959
Email:crystal_admin at
Website:
Tancheng Development Zone,Linyi City,Shandong Province,China
