China products QT4-15B brick making machinery alibaba com germany
China products QT4-15B brick making machinery alibaba com germany information:
1. Area: Workshop area: 150-200m2, all factory area 2000m2, the bigger, the better.
2. Workers : five or six
3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.
4.Hollow block weight:
(400*200*200) :17KG,(400*150*200):13.5KG,(400*100*200):10KG
5. Raw material consumption per day:100-110T
6. Water consumption per day:3%-5% of raw material .Weight.
QT4-15B guarantee:
We give our brick making machine one year guarantee,during the period we can supply spares if they are broken.
pressure of QT4-15B:
Hollow blocks can reach 8-10Mpa,Solid bricks can reach 10-12Mpa,so they have a higt pressure,can be widely used.
Main technical parameter:
Dimension of host machine |
3000x2200x2600mm |
Host machine power |
24kw |
Weight of the host machine |
8.5T |
Shaping period |
15-20s |
Vibration force |
60KN |
Vibration Frequency |
2850/min |
Mixer |
JS500 |
Voltage |
380V |
General water consumption |
4.5T/day |
Capacity of QT4-15B:
Item |
Picture |
Specification(mm) |
pcs/mould |
Psc/h |
Concrete brick |
|
390*190*190mm |
4 |
6500 |
Solid brick |
|
240*115*53mm |
26 |
40000 |
Porous brick |
|
240*115*90mm |
14 |
12000 |
QT4-15B have the below advantages:
1:Imported elector -hydraulic proportional control valves ,it can reduce the impacts to the machine ,prolong the working life.
2:Frequency conversion control technology is used , the speeds and pressures can be adjusted ,it will make the operation running smoothly and steady ,reduce the noises and impacts.
3:Equiped national standard steel.
4:The main section are treted by carburizing ,it is sturdy and wear resisting.
5:With trouble warning system,easy to find fault.
Production line:
Our certification
Our factory
