Introduce of fine impact crusher:
This series of fine crusher is a new kind highly efficient crusher, which has been developed and improved by incorporating the advanced technologies both at home and abroad. It is widely used for fine crushing of all kinds of solid materials, such as limestone, gypsum, clinker and other mixing materials with medium hardness in the cement industry. It also can be used for fine crushing the calcium phosphide dolomite, perlite ore and so on in the building materials, chemical fertilizer, quarry, and refractory industries.
Operating Principle of fine impact crusher:
Fine Impact Crusher is a kind of crushing equipment which uses impact energy to crush maters. When getting into the effective area of hammer plates, due to the high speed of striking, the raw materials are thrown onto the impact equipment which is intalled above the rotor. Then the materials are rebounded to the effective area of hammer plates and crushed again in the crushingchamber. At last, when the particles reach to the proper size, they will b edischarged from the bottom of the machine.
Fine Impact Crusher Features:
Fine crusher, a type of Impact Crusher is mainly used in secondary crushing. It can crush various rocks, high efficiency, easy maintenance, and cubic shape of the products. Impact crusher is widely used in mining, highway, and construction.
Impact crusher 's electric motor drive the rotor to high speed, when the material was fed to the crushing chamber from feed inlet, the material will be struck by the plate hammer on the rotor, then will be thrown to the impact plates, after struck repeatedly, the final products will be discharged from the crusher.
|
Model |
Feeding size (mm) |
Output size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
PCX800*300 |
<60 |
<5 (96%) |
20-25 |
37 |
2.5 |
PCX800*600 |
<60 |
<5(94%) |
35-50 |
45 |
4.7 |
PCX800*800 |
<70 |
<5(92%) |
40-60 |
75 |
6.5 |
PCX1000*1000 |
<80 |
<5(91%) |
60-90 |
90 |
8.8 |
PCX1000*1200 |
<90 |
<5 (88%) |
75-110 |
110 |
13.6 |
PCX1300*1200 |
<100 |
<5(86%) |
120-145 |
160 |
19.5 |
PCX1300*1400 |
<120 |
<5 (85%) |
145-180 |
180 |
26 |
