Help Center300w Dolphin Wind Turbine Generator 12V/24V Optional With CE.ROHS,ISO9001 Certification.
Related Products
-
300W Max Horizontal Wind Generator Used for Home&marine.US$ 225 - 290MOQ: 1 Piece -
Horizontal Wind Generator 300w Used for Boat . Factory Price and High Quality +wind Controller.US$ 200 - 235MOQ: 1 Piece
-
12V/24V Wind Generator 300w Horizontal Axis+wind/solar Hybrid Controller+inverter.US$ 235 - 270MOQ: 1 Piece
-
Brand New 300W Wind Generator for Marine&land With 6 PCS Blades+wind/solar Hybrid Controller(LCD Display).US$ 250 - 285MOQ: 1 Piece
-
Wind Generator Motor 300w Hyacinth 12V/24V+wind Controller.CE,ROHS,ISO9001 Approval.US$ 225 - 260MOQ: 1 Piece
Specifications
wind turbine generator1.Start in breeze 3.5m/s
2.Spinning then charging
3.High efficient output.
4.CE,ROHS,ISO9001
300w dolphin wind turbine generator 12V/24V optional with CE.ROHS,ISO9001 certification.
Sample Purchase online: Click here
Please leave a message about whether you need
12V or 24V.
Introduction
1. Large power, low volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
Technical Data
Model |
Dolphin-300 |
Rated Power |
300W |
Rated Voltage |
DC/AC 12V/24V |
Rated Current |
25A/12.5A |
Rated Speedy |
1850r/m |
Max Power |
380W |
Number of blade |
3 PCS |
Start-up wind speed |
3.5m/s |
Cut-in wind speed |
3.5m/s |
Cut-out wind speed |
18m/s |
Security wind speed |
45m/s |
Rated wind speed |
12.5m/s |
Engine |
Three-permanent magnet generator |
Rotor diameter |
1250mm |
Blade material |
Carbon fiber |
Output line anti-winding device |
Overall three-phase commutator |
Over-speed wind protection |
Tip stall protection + turned protection + Electromagnetic brake |
Life span |
15years |
Equipment surface protection |
Aluminum oxide+plastic coating |
Working temperature |
-45°C to 70°C |
N.W. |
5.85kg |
packing dimension |
690*380*220mm |
G.W. |
7.5kg |
Drawing |
|
|
300W monthly power generation curve |
|
Powe curve |
|
Certification |
|
Description
1.simple structure,running stably,power supply for city lamp,monitoring and home.
2. Small size and flexibility,lively Colors,beautiful curve,low noise and environmental harmony.
3. Anti-Rust,Anti-Corruption Damp-Proof,Water-Proof,Stand-Proof.
4. Brand New in box
5. CE Certificate
6. ISO9001:2000 Quality Certification
7. ROHS Certification
8. Large power, low volume, high efficiency
9. High efficiency of anti-wind ability,move mutely and steadily
10. Blades with the ability of automatically stall protection under strong wind
11. 3 years free warranty
Application
