Home > Manufacturing & Processing Machinery > Crane > Other Cranes > SCP200/12D Work Platform

SCP200/12D Work Platform

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

TDT

Model Number:

SCP230/9D,SCP200/12D

Certification:

Contact Supplier Request Quote Chat Now

Wuxi Huake Machine Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name TDT

Model Number SCP230/9D,SCP200/12D

Certification CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

1500-3600kgs capacity; 250m max working height. 30m max working platfrom length

Safety devices of the Mast Climbing work platform MC-3615 : -Self braking motors. -Hot-dip galvanized structural elements for a long duration. -Double safety limit switches up and down -Safety interlocks on access gates -Audio travel alarm -Base leveling screw jacks with safety locks -Safety top mast section with interrupted rack -Phase control and over charge electrical protection -Twin mast automatic self leveling device -Emergency No power manual descent device -Emergency Stop Button -Emergency parachute Brake.
Technical Specification: -Max Weight 250m -Platform width 1,3m -Extensions length 1m -Distance between ties 6m/9m -Mast Section height and weight 1,5m 41 KG -Length/weight platform sections 1,5m 103Kg/1m 70 Kg -Weight of drive unit with base 762 Kg -Lifting Speed 6m/min -Three-phase power supply 50/60 Hz 230/400 V

PLATFORM TYPE	TWIN MAST MC-36/15e ASCLIMBER	SINGLE MAST MC-36/15e ASCLIMBER
Maximum height	332.18 ft	332.18 ft
Maximum distance from ground to first anchoring	19.68 ft	19.68 ft
Maximum total capacity	7936.6 lb	3307 lb
Maximum distance between anchors	29.52 ft	19.68 ft
Maximum length of working area	98.75 ft	32.15 ft
Width of working area	4,43 ft	4,43 ft
Maximum extension towards wall	3,12 ft	3,12 ft
Motor power (BN 100LA - FD 15)	4x2,2 KW	2x2,2 KW
Elevation speed	20.3 ft/min	20.3 ft/min
Geared motor electrical consumption	2x5,4A	5,4A
Consumption upon elevation start	2x24,3A	24,3A
Power supply	400V-50Hz	400V-50Hz
Maximum allowed wind speed in service – w/o anchors	28.4 mi/h	28.4 mi/h
Maximum allowed wind speed in service	34.6 mi/h	34.6 Km/h
Maximum force against rails	198.5 lb	198.5 lb
Maximum wind speed during mounting/dismounting	28.4 mi/h	28.4 mi/h
Maximum wind speed when out of service	102.6 mi/h	102.6 mi/h
Leq Acoustic level	60 dB(A)	60 dB(A)
