Specifications
Original New FortiGate-80C Fortinet Security Appliance FG-80CFortinet Security Appliance
FortiGate-80C
FG-80C ...
The FortiGate/FortiWiFi-60, 80 and 90 series are compact, all-in-one Network Security Appliances that deliver Fortinet’s Connected UTM solution. Ideal for remote locations, customer premise equipment (CPE) and retail or healthcare networks, the FortiGate/FortiWiFi-60, 80 and 90 series appliances offer the network security, connectivity and performance you need.
With Connected UTM you get a single device that integrates comprehensive enterprise-grade protection with a broad range of Wired and Wireless connectivity options. It enables you to deploy a high-performance, highly secure remote infrastructure with one appliance that’s easy to set up and centrally manage.
- Comprehensive network security, including Application Control, IPS, Advanced Antimalware, Web Filtering, VPN and WAN Optimization
- Simple per-device pricing eliminates the need to count users or license additional modules.
- Firewall throughput up to 3.5 Gbps prevents your network security from being your network bottleneck
- Optional Power over Ethernet (PoE) support enables you to connect Wireless Access Point, 3G4G Extenders, VoIP Handsets and IP Cameras to your network security platform and away from power supplies.
Connected UTM optimizes your complex network and makes it easier for your IT staff to improve your security, simplify your infrastructure, and lower your TCO.
| Technical Specifications | FortiGate-80C | FortiGate-80CM | FortiWifi-80CM |
|---|---|---|---|
| Hardware Specifications | |||
| 10/100/1000 WAN Interfaces (Copper, RJ-45) | 2 | 2 | 2 |
| 10/100 Internal Switch Interfaces (Copper, RJ-45) | 6 | 6 | 6 |
| 10/100 DMZ Interfaces (Copper, RJ-45) | 1 | 1 | 1 |
| Management Console Interface (Copper, RJ-45) | 1 | 1 | 1 |
| USB Interfaces | 2 | 2 | 2 |
| ExpressCard Slot | 1 | 1 | 1 |
| WLAN Support | - | - | 802.11 a/n or b/g/n |
| Analog Modem | No | Yes | Yes |
| Internal Storage | 8 GB | 8 GB | 8 GB |
| System Performance | |||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 1900 / 700 / 120 Mbps | ||
| Firewall Latency (64 byte UDP packets) | 45 μs | ||
| Firewall Throughput (Packets Per Second) | 180 Kpps | ||
| Concurrent Sessions (TCP) | 1 Million | ||
| New Sessions/Sec (TCP) | 12,000 | ||
| Firewall Policies | 5,000 | ||
| IPSec VPN Throughput (512 byte packets) | 140 Mbps | ||
| Gateway-to-Gateway IPSec VPN Tunnels | 200 | ||
| Client-to-Gateway IPSec VPN Tunnels | 1,000 | ||
| SSL-VPN Throughput | 70 Mbps | ||
| Concurrent SSL-VPN Users (Recommended Max) | 60 | ||
| IPS Throughput | 350 Mbps | ||
| Antivirus Throughput (Proxy Based / Flow Based) | 50 / 190 Mbps | ||
| Virtual Domains (Default / Max) | 10 / 10 | ||
| Max Number of FortiAPs | 16 | ||
| Max Number of FortiTokens | 100 | ||
| Max Number of Registered FortiClients | 10 | ||
| High Availability Configurations | Active/Active, Active/Passive, Clustering | ||
| Unlimited User Licenses | Yes | ||
| Dimensions | |||
| Height x Width x Length | 1.75 x 10.87 x 6.13 in (4.45 x 27.61 x 15.57 cm) | ||
| Weight | 3.3 lb (1.5 kg) | ||
| Wall Mountable | Yes | ||
| Environmental | |||
| Power Required | 100-240 VAC, 50-60 Hz | ||
| Power Consumption (AVG / Max) | 25 / 30 W | 26 / 31.2 W | 28 / 33.6 W |
| BTU | 102.3 BTU | 106.5 BTU | 115 BTU |
| Operating Temperature | 32 to 104°F (0 to 40°C) | ||
| Storage Temperature | -31 to 158°F (-25 to 70°C) | ||
| Humidity | 20 to 95% non-condensing | ||
| Compliance & Certification | |||
| Compliance | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB | ||
| Certification | ICSA Labs: Firewall, IPSec, IPS, Antivirus, SSL VPN | ||
-
