BF flotation machine
Product Features
SF flotation machine is suitable for separating non-ferrous metals, ferrous metals, precious metals, non-metallic mineral and chemical raw materials, recycling of useful minerals. The device has the following characteristics: inspiratory capacity, low power consumption. Each slot both suction, suction slurry and flotation triple features, since as flotation circuit, without any auxiliary equipment, the level of configuration, ease of process changes. Slurry circulation reasonable, to minimize sand sedimentation. Slutty controlled device, easy to adjust. Impeller with backward curved blades up and down. Leaves on the pulp cycle, the next leaves the pulp cycle.
Working principle of this machine:
Application:
The mineral products floatation machine is widely applied in the rough selection,secondary selection,and counter-floatation selection of copper,lead,zinc,nicket,molydenum and other non-ferrous metal,black metal and non metal minerals
Notes for selection
While placing your order, in addition to specifying the model and quantity, make sure to provide the flotation circuit and the followings
Configuration scheme and the feeding mode
Quantity of the scrapers and mode of drive(right drive or left drive)
Quantities of feeding chambers, intermediate chambers, and crude ore chambers
Other special requirements.
No electric control cabinet will be supplied.
The flashboard will be made according to the manufacturer’s drawings. And the electric driven flashboard will be adopted for large scale flotation machine.
Technical parameter list of BS-k flotation machine
Model | Effective Capacity
| Capacity
| Diameter of Impeller | Revolution of Impeller | Motor Power | Weight of single | |
For Agitating | For Scraper | ||||||
| m³ | m³/min | mm | r/min |
|
| kg |
SF-0.37 | 0.37 | 0.2-0.4 | 300 | 352-442 | 1.5 | 0.55 | 470 |
SF-0. 7 | 0.7 | 0.3-1.0 | 350 | 336 | 3 | 1.1 | 970 |
SF-1.2 | 1.2 | 0.6-1.6 | 450 | 312 | 5.5 | 1.1 | 1400 |
SF-2.8 | 2.8 | 1.5-3.5 | 550 | 268 | 11 | 1.5 | 2242 |
SF-4 | 4 | 2-4 | 650 | 235 | 15 | 1.5 | 2600 |
SF-8 | 8 | 4-8 | 760 | 191 | 30 | 1.5 | 4292 |
SF-10 | 10 | 5-10 | 760 | 191 | 30 | 1.5 | 7415 |
SF-20 | 20 | 5-20 | 760 | 191 | 30*2 | 1.5 | 9823 |
Before sales: Guide customer to choose the most suitable type of equipments; provide advanced, energy-saving and practical flow chart as well as responsible for designing the whole schem.
On sales: Inspect the product seriously before out of the factory; Invite customer for commissioning in the spot and raising the objection:Organize to delivery according to the contract.
After sales: Company can send technical persons for guiding to install ,debugg and train the workers.We will provide one-year warranty to make sure your machine work well. We have spare parts of the very machine in stock all the time which means the replacements can be sent to you timely.
Shandong (Zhaoxin) Mining Machine Group Company is ISO9001-2008 certificated. With 30 years manufacturing experience and scientific management and strong financial strength ,the company has become a large and leading manufacturer in mineral processing and smelting equipment for nonferrous metals and nonmetals in Shandong area .Zhaoxin machinery has exported to 20 and more countries.The company mainly manufactures mineral processing and smelting equipment with daily processing capacity of 50 to 5000 MT and automatic control equipment with 20 varieties and more than 200 items. Among processing equipment , there includes feeding, crushing, sieving, grinding, classification, stirring, flotation, magnetic separation and cold separation. Moreover , the company offers full service from mining, prospecting, mineral processing experiment, project technical design, machinery and equipment installing to technical conduction and operators training.
Cetificates
Application:
-Mining and mineral process
-Iron ore processing plant
-Sump sewage transfer
-Submersible liquid
-Coal washing plant
-Gold mining company
-Dredging process
-Gravel & sand process
-Trash handle
-Tailing handle
-Mud pump
If you have any problems, please feel free to contact us. We would do our best to solve them as soon as possible. Welcome to negotiate price, you can gain the maximum efficiency with the minimum investment.
