VFL6502 650nm Visual Fault Locator

Specifications

VFL6502 series 650nm Visual Fault Locator is the best selling model.

It adopts the aluminum alloy case, which could be painted to different colors. The aluminum alloy material makes touching more confortable and smooth.

VFL6502 series  650nm Visual Fault Locator provides a stable visible red light for users to easily

locate fiber faults, broken or micro-bend in installation or maintenance of optical network.

With the modulation function, it is also applicable for end to end fiber identification.

Features

• 650nm Visual Fault Locator
• Aluminum alloy body and light weight
• Removable ferrule

• Multi output power available
• 2.5 mm universal connector
• Constant and stable output power
• CW or 2Hz modulated signal
• Low battery warning
• Up to 60 hours battery life

Specification

Standard Accessories

1)     Main Unit

2)     Battery

3)     Cleaning Stick

4)     Carrying Bag

Ordering Information

VFL6502-OP

1)  OP=Output Power

     OP1: 1mw

     OP2: 3mw

     OP3: 5mw

     OP4: 10mw

     OP5: 15mw

     OP6: 20mw

     OP7: 30mw

     OP8: 45mw

     OP9: 60mw

1. Standard warranty is 18 months.

2. Extended warranty is also available as per your request.

1)  650nm Visual Fault Locator +battery+replacement ferrule+carrying pouch+battery+box
