FI6600 Traffic Identifier

FOB Price

USD $200 - $800 / Piece

1 Piece(Min.Order)

Supply Ability 30 Piece / Pieces per Month
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Sinomor
Model Number	FI6600

Product Description

Specifications

1. Traffic identifier
2. Handheld and rugged mental case
3. One-key operation
4. In-line test

Overview

FI6600 traffic identifier is a rugged and easty-to-use instrument to identify the signal absence or presence,transmitting direction,relative core power and moludation of the fibers.

By inserting the fiber to the probe of FI6600 traffic identifer,it realizes the in-line test without interruting the current service.

When the traffice is present ,an intermittently audible tone would be heard;when the modulation is detected,the continously audible tone would be heard.

FI6600 traffic identifier is provided with 4 interchangeable conectors which are seperately for bare fiber,loose tube fiber and jacketed fiber.

Features

Handheld and rugged mental case for field work
Easy-to-use with “ONE KEY” operation.
In-line test without interrupting current service
Detection of signal presence or absence, signal direction
Detection of modulation 270Hz,1kHz or 2kHz with audible warning
Display of the relative core power
Easy-to-replace adapters to accommodate different fibers
Lower power indication

Specifications

Model	FI6600
Wavelength Range (nm)	800~1700
Detector Type	InGaAs (Ø1mm 2pcs)
Connector	Ø0.25/ Ø0.9/ Ø2.0/ Ø3.0
Signal Direction	Left & Right
Signal Direction Test Range (dBm, CW/ Ø0.9mm)	-46~10 (1310nm)
	-50~10 (1550nm)
Signal Power Test Range (dBm, CW/ Ø0.9mm)	-50~+10
Signal Frequency Display (Hz)	270, 1k, 2k
Frequency Test Range (dBm, Average Value)	Ø0.9, Ø2.0, Ø3.0	-30~0 (270Hz,1KHz)
		-25~0 (2KHz)
	Ø0.25	-25~0 (1KHz,2KHz)
		-20~0 (2KHz)
Insertion Loss (dBm, Typical Value)	0.8 (1310nm)
	2.5 (1550nm)
Battery	9v
Operating Time (h)	10
Operating Temperature (°C)	-10-+60
Storage Temperature (°C)	-25-+70
Dimension (mm)	196X30.5X27
Weight (g)	200

Standard Accessories

1) Main Unit

2) 250mm Adapter

3) 900mm Adapter

4) 2000mm Adapter

5) 3000mm Adapter

6) Sunshade Cover

7) Cleaning Stick

8) Battery

9) Carrying Bag

10) Manual

Ordering Information

FI6600-S

1) S=Standard
