Common Rail System Tester

FOB Price

US$ 500 - 1,480 / Set

1 Set(Min. Order)

Port Tianjin
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China		Brand Name	Injectronix
Model Number	CRS-4000		Warranty	1 Years

Product Description

Specifications

Common Rail System Tester
Best Tech Support
One year manufacture warranty
Test data is from Bosch.

CRS-4000 Common Rail System Tester

is a cost-effective,modular designed equipment to test all kinds of diesel common rail fuel injection systems.

Features:

CR Injector Drivers:

6 solenoid injectors

High voltage for Bosch, Denso injectors

Low voltage for Delphi injectors

6 piezoelectric injectors, made by Siemens and Bosch (optional module)

Short circuit protection for both solenoid and piezo injector drivers

CR Pump Drivers:

Multiple independent PWM (Pulse Width Modulation) output channels to drive pump solenoids

Testing pumps with single regulation valve

Bosch CP1/CP2/CP3

Delphi CRSP

Denso HP3/HP4

Testing Siemens DCP pump with two regulation valves

Drive 3 DRVs for testing pump capability

2 special output channels synchronous with pump speed to drive the two control solenoids on Denso HP0 (ECD-U2)pump (optional module)

Fuel Rail Pressure Sensor

Pre-calibrated data for Bosch, Delphi, Denso pressure sensors

Automatic (close-loop)rail pressure control

Software based over-pressure protection

User Interface

Small key pad

Large LCD screen

Others

One year manufacture warranty

Injector and pump test procedure and database, off-line

DRV adaptor for pump flow rate test (Optional)

Rich accessories
