CRB-100 Common Rail Injector Test Bench

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China	Brand Name	Injectronix
Model Number	CRB-100	Power	Electronic
Usage	Auto Testing Machine

Product Description

Specifications

Complete pneumatic driven test bench to test a common rail injector with either solenoid or piezo technologies.

CRB-100 Common Rail Injector Test Bench

Common rail injector test bench CRB-100 is designed to test one common rail injector with either solenoid or piezoelectric technologies. The test bench integrates an ultrasonic cleaner for cleaning the sophisticated injector components.

Function:

Measuring fuel delivery of a common rail injector
Checking injector nozzle spray pattern
Cleaning sophisticated components of injectors

Specification

Using pneumatic amplifier actuator to generate high pressure fuel source to feed the injector
a) Required shop compressed air supply, 6-8bar,out flow 150L/min
b) Fuel Pressure range 0-1200bar
c) Fuel type: diesel fuel
d) Fuel Pressure stability +/-50bar

Simulate engine ECU signals to drive either a solenoid or a piezoelectric actuator in a common rail injector
a) Adjustable injection frequency, represented by engine speed, 0-4000rpm
b) Adjustable injection pulse width or injection duration, 0-6ms

Fuel delivery measurement

a)Injection counter set: 0-9999 injections
b) Fuel delivery measured by glass graduates, for both fuel injection and injector leakage

Fuel filtration: 5µm
Integrated ultrasonic cleaner
a) Power: 360W
b) Basin dimension(mm): 300×240×150

Main AC power, single phase, 500W, 220V/50Hz, or 115V/60Hz, or per customer specification

Test bench base dimension(mm): 1550×850×650
Test bench weight: 250kg

Rich accessories
