Specifications
1.Imported high speed side rail, highspeed and high precision2.Newly motherboard and software, support CorelDRAW output.
Main paramaters:
| Laser Tube Wattage | 50Watt (Optional) |
| Laser Type | Sealed Co2 Glass Laser Tube |
| Laser Cooling | Water Cooling |
| Work Area(mm) | 400x600 mm(15.75"x23.62") |
| Lifting Height of worktable(mm) | 130mm(5.12") |
| Engraving Speed | 50-400mm(1.97"-15.75")/s |
| Cutting Speed(mm/s) | 6-30mm(0.24"-1.18")/s |
| Positioning Accuracy(mm) | ±0.05mm(0.0019") |
| Comuputer Interface | USB port |
| Graphic format supported | AI,PLT,DXF,BMP,DST,DWG,LAS,DXP,CDR,etc. |
| Appearance size(mm) | 1100x750x1050mm(43.30"x29.53"x41.34") |
| Packing size(mm) | 1480x880x670 mm(58.27"x34.65"x26.38") |
| Net weight(Kg) | 64 kg |
| Gross weight(Kg) | 140 Kg( wooden packaging) |
| Packing | Plywood case |
| Electrical Requirements | AC 220V / 50Hz |
| Warranty period | 1 year |
Optional device |
1. Front-loading fan; 2. Infrared locator; 3. Rotary device. |
Application area: Personalized crafts,gifts,Gass crafts, Packaging and Printing,paper-cutting industry,clothing,leather and stamp making industries.
Application materials:
| Marble carve portrait | yes |
| Personalized materials processing | yes |
| Personality pendant,acrylic,breastplate,mobile shell,flash drive, plexiglass | yes |
| Crafts and gifts:Photo frames,glass cup,packaging | yes |
| Crystal jewelry:jade,stone,crystal | yes |
| Garment leather:leather,fabric,cowboy | yes |
| Paper industry:Paper-cutting,window grilles | yes |
Features:
1. Imported liner high speed side rail, high speed and high accuracy.
2. Newly professional motherboard and software, powerful and support CorelDRAW output.
3.Current LTD monitor, easy to operation.
Machine Parts:
Elfin-4060 |
|
Panel |
Work platform |
Power box |
|
Exhaust fan |
Water Pump |
Air pump |
Sample show:
|
|
|
|
|
|
Sales packaging: Each machine with a standard export wooden box.
Warranty and Service:
1.one year equipment warranty and maintenance for lifetime.
2.free installation and test before sending and free training for operators
3.advice for the solutions best for customers requirements.
4.free training and sample provided
Henan Wotafune Digital Technology Co.,Ltd is a highly scientific and technical enterprise which integrates research, development, production and sale together and is the first factory engaged in digital foil stamping machine in China since 1997 With 15 years experience in producing digital foil stamping machines,foil heat transfer machines, digital foil printing machine, cutting plotter and sea shell laser engraving machine in China, Tianrong proudcts(Amydor brand)such as our sea shell laser engraving machines have been sold to wordwide such as Thailand,UK,Malaysia,Germany,Italy,Tanzania, Philippines, Brazil and so on with high quality,competitive price mugs laser engraving machine and good service.
Wotafune welcomes all customers around the world to establish great business relationships and share success together.
Please advise us the following information, so that we can recommend you the most suitable machine, right now, free to contact us:
1. what kind of machine do you need? laser cutting,laser welding or laser marking machine?
2. What materials do you need to process? The size and thickness? jade, crystal, plexiglass, wood or seal material or others material? 0.1mm thickness or 5m thickness?
We will be very happy to help you in any way we can.
