Home > Products > Inline Fan > Quiet Hydroponic Inline Fan Flexible Fan Blower Ventilation Fan
Quiet Hydroponic Inline Fan Flexible Fan Blower Ventilation Fan
- Xiamen
- T/T Credit Card
You May Like
Product Details
| Electric Current Type | AC | Blade Material | Stainless Steel | |
| Mounting | Duct Fan | Brand Name | Orientrise | |
| Model Number | ORIF100 | Power | 190W | |
| Voltage | 120V/60Hz,230V/50Hz | Air Volume | 290-2350㎡/h | |
| Speed | 2600-2900 | Certification | CE | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
Quiet Hydroponic Inline fan flexible fan blower ventilation fan
Inline fan is used in the growing room to exchange stale air with fresh air to keep temperature and humidity under control and cool your reflector.
The fan is suitable for operation at any angle and delivery exceptional airflow performances against the high static pressure.
The inline duct fan features high power motor and aerodynamically designed shape. It is able to move air through long stretches of ducting, grow light reflector or carbon filters.
Consist of housing, impeller, motor, bracket and connection box, the brief design making it easy to use.
It is quick to install and uninstall, and the impeller and the motor are combined to a whole with small volume and litter install space, mini size, reliable performance, high efficiency and long life.
Specific technical parameter:
Model | Voltage | Frequency | Power | Rotate | Air Flow | Pressure |
(HCEU) | (V ) | (HZ) | (W) | (R/Min) | CFM | (Pa) |
Φ100mm | 120 / 230 | 60 / 50 | 69 | 2600 | 100 | 360 |
Φ125mm | 120 / 230 | 60 / 50 | 71 | 2600 | 195 | 390 |
Φ150mm | 120 / 230 | 60 / 50 | 100 | 2510 | 265 | 430 |
Φ160mm | 120 / 230 | 60 / 50 | 130 | 2520 | 285 | 475 |
Φ200mm | 120 / 230 | 60 / 50 | 190 | 2520 | 470 | 620 |
Φ250mm | 120 / 230 | 60 / 50 | 195 | 2540 | 650 | 635 |
Φ315mm | 120 / 230 | 60 / 50 | 250 | 2540 | 950 | 720 |
Main features:
- Drive by external rotor motor, powder coated in black
- Thermal protector AC motor
- Aerodynamic design allows more air flow
- UL recognized components
- Mounting bracket included
- Permanently lubricated bearings
- engineered for maximum boost with minimum noise
- Blade material is polyca
Trade term & Payment term
Trade term: EXW, FOB, CIF, CFR
Payment term: Sample order requests full payment in advance, bank transfer or Paypal acceptable
Bulk order request 30% initial deposit and 70% balance before shipping, bank transfer only
rbonate
What can I do for you?
*Design for products and custom tailor
*One-Stop-Purchase service
*Whole course of quality control
*Timely arrange for delivery
*Unobstructed communion
Main products: grow tent,dry net,bubble bag,lighting reflector,carbon filter
Main markets: North America, Western Europe, Oceania, Southern Europe, Northern Europe
Our value: Better, Faster, Cheaper!
As a professional manufacturer and exporter of gardening equipment in China, we have three subsidiary factories which specialize in different fields: grow lights, grow tents, grow pots, carbon filters and bubble bags. We hold the production principle of "we should be responsible for our customers, for the quality of our products and for our shareholders, that is, for every staff member".
Not exactly what you want? Welcome to ask questions at any time!!!
