Intel Haswell/Broadwell U-series Industrial Computers NIS-H899

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port SHENZHEN
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	Embedded Computer
Brand Name	YACOO	Model Number	NIS-899
Place of Origin	Guangdong, China

Product Description

Specification
Processor	CPU	Intel^® Haswell/Brodwell U-series CPU (Duo Core),Celeron/I3/I5/I7 CPU compatible,15-28W CPU
	CPU Package	Onboard
	FSB	DMI
	Chipset	Intel® Haswell/Brodwell U-series
	BIOS	System BIOS: SPI BIOS,Chargeable CMOS battery 65mah
Memory	Architecture	Single Channel Low voltage DDR3 1666 MT/s
	Capacity	MAX 16GB
	Socket	SODIMM
Display	Graphic Controller	Intel® HD4000/5000/6000 series Graphic media accelerator
	DVI	DVI-I port, Max. resolution:4K
	VGA	Support VGA output
	Dual Display	VGA+DVI Synch. Or Asynch. Display
LAN	Controller	LAN1: Intel®I210 GbE network
		LAN2: Intel®I210 GbE network
		POE POWER Module (optional)
Audio	Controller	Realtek HD ALC662 audio decoder(right&left channel + MIC)
Super I/O	Controller	NTC6106 SIO
H/W Monitoring	Watch Dog Timer	0-255 sec., provide watch dog routine
H/W Monitoring	Temp. Detect	Support CPU/Motherboard/HDD temp. detect
I/O	USB 3.0	2 x USB 3.0 PORT
	USB 2.0	4* USB2.0 / 1.1 (compatible),support max.+5V@1A.
	Serial Port	Com1 9-wire RS232/RS485 optional ,PIN9 jumper select +5V/+12V/RING,TX/RX signal, support 4000V surge protection
		Com2 3-wire RS232TX/RX signal, support 4000V surge protection
		Com3-COM4 3-wire RS232/RS485 optional,RS232 TX/RX signal,support 4000V surget protection,RS485 support isolation protection
		COM5-COM6 3-wire RS232TX/RX signal, support 4000V surge protection
	GPIO	12 bit, provide routine, freely degine I/O,3.3V@24mA level
Expansion BUS	LPC BUS	Support,4*COM scalable
	SMBUS	Support,multi GPIO scablable
	Mini-PCIe	1* half-size Mini-PCIe socket, support PCIe & USB device
		1*full-size Mini-PCIe socket, support USB 3G/4G communication module
		3G UIM socket
	3 Extended Modes	1.2-way PCI extendible
		2. 1-way PCIE 4X, and 1-way PCIE 1X extendible
		3. 1-way PCIE 4X, and 1-way PCI extendible
TPM Encryption		Optional
Storage	SATA	2*standard 7PIN SATA connector,plus externalSATA HDD power connector
Storage	M-SATA	1* full-size m-SATA scoket, max transmission rate: 3Gb/s
Power	Power Type	AT/ATX mode via jumper selection,DC+9V-30V input, LTM3780 power design, support power reverse and over-voltage protection. 3PIN 5.08mm phoenix connector.
LED Status Indicator	LED	HDD LED
LED Status Indicator	LED	POWER LED
Environment	Operating Temp.	-20°C ~ 60°C
	Storage Temp.	-40°C ~ 80°C
	Operating Humidity	0% ~ 90% relative humidity, non-condensing
	Storage Humidity	0% ~ 90% relative humidity, non-condensing
	Dimensions	260 x 225 x 105mm
	Weight	4.2KG
	Certificate	FCC, CE, RoHS standard
