Intel Haswell/Brodwell U-series 3.5" Single Board Computer ENC-H900

Intel Haswell/Brodwell U-series 3.5" Single Board Computer ENC-H900 thumbnail-1
Intel Haswell/Brodwell U-series 3.5" Single Board Computer ENC-H900 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Chipset Manufacturer:
Intel
Socket Type:
Other, Onboard
Contact Supplier Request Quote Chat Now
Shenzhen Yacoo Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Chipset Manufacturer Intel
Socket Type Other, Onboard
Form Factor Other, 3.5"
Memory Type DDR3
Graphics Card Type Integrated
Brand Name YACOO
Model Number ENC-H900
Place of Origin Guangdong, China
Specification
Processor CPU              Intel® Haswell/Brodwell U-series 15W CPU (Duo Core)
CPU Package Onboard CPU. (Celeron 2957U & I3 can be fanless design)
Chipset Intel® Haswell/Brodwell U-series SOC
BIOS             System BIOS: SPI  BIOS,CMOS battery
RAM Architecture Single Channel DDR3 1066 MT/s
Capacity Onboard 4GB DDR3
Socket N/A
Display Graphic Controller Intel® HD4/5/6000 series graphic media accelerator
HDMI Max. Resolution 4K
VGA Support VGA output
LVDS Dual Channel LVDS
Three Display LVDS+VGA+HDMI Synch. Or Asynch. Display
LAN Controller LAN 1: Intel®I210 GbE LAN
LAN 2: Intel®I210 GbE LAN
Audio Controller Realtek HD ALC662 Audio decoder(right&left channel + Mic)
Super I/O Controller NT6106,Support 6*COM
H/W Monitor Watchdog Timer 0-255 sec., provide watchdog routiine
Temp. Detect Support CPU/Motherboard/HDD temp. detect
I/O USB 3.0 4 x USB 3.0 PORT
USB 2.0             2*USB2.0 / 1.1 compatible, support max.+5V@1A.
Serial Port Com1-2 9-wire RS232,COM1 PIN10:+5V
Com3-COM4 3-wire RS232
Com5-COM6 3-wire RS232/RS485 optional
GPIO 12bit,provide routine,freely define input/output,3.3V@24mA level
Expansion Bus LPC BUS Support,for Extensible 4*COM
SMBUS Support,for extensible GPIO
Mini-PCIe 1*half-size Mini-PCIe socket, support PCIe & USB device
1*full-size Mini-PCIe socket, support USB 3G/4G module
3G UIM socket
Storage SATA             Standard SATA connector,and SATA HDD power connector
M-SATA 1*full size m-SATA  scoket,  max. transmission rate:3Gb/s
Power  Power Type AT/ATX power mode optional (jumper selection),DC9-30V input, LTM3780 power design, support power reverse protection.
Power Consumption Typical Power: 15W
Environment Operating Temp. -20°C ~ 60°C
Storage Temp. -40°C ~ 80°C
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Storage Humidity 0% ~ 90% relative humidity, non-condensing
Dimensions 145 x 102mm, standard 3.5"
Weight
Certificate FCC, CE, RoHS
