Good performance with competitive price 600kw 750kva rated power by Yuchai engine

Name: Good performance with competitive price 600kw 750kva rated power by Yuchai engine
Brand: Yuchai
Price: USD $55,000 - 59,000 / Set

FOB Price

USD $55,000 - $59,000 / Set

1 Set(Min.Order)

Product Details

Good performance with competitive price 600kw 750kva rated power by Yuchai engine

Genset Information
Model	GF-600	Net dimensions (mm)	350013002100mm
Prime Output(kw/kva)	600kw/750kva	Gross weight (kg)	5800kg
Rated voltage(V)	400V/230V(adjustable)	Net weight (kg)	5600kg
Rated current(A)	1080/1188A	Noise (dB)	100DB(A)
Electric Parameter	50/60HZ,1500RPM,400/230V,Power Factor 0.8(Lagging),6 Pole
Generator configurations
Engine Brand:	Yuchai	Rated output(kw):	600kw/750kva
Engine Model:	YC6C1020L-D20	Bore (mm)	200*210mm
Induction System	Turbocharging	Cylinder No.	6
Cooling method	Closed circulating water cooling	Speed	1500rpm
Lubricating capacity(L)	64L	Governor	110%
Alternator configurations
Alternator Brand:	YONGFENGSHENG	Protection Grade	IP22
Alternartor Model:	TFW-600	Output Type	Three phase four wire type y connection
Rated output (kw/kva)	600kw/750kva	Excitation method	AVR(Automatic voltage regulator)
Rated voltage(V)	400V/230V	Frequency (HZ)	50/60HZ
Insulation Grade	H Class	Power Factor	COS=0.8

Xiamen Fengyuan Power Machinery Co., Ltd.: Contact nameNicole Wang; Phone86-592-5233679; Address19,Xiangyu Road,Huli Area,Xiamen City Xiamen,Fujian
