Pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED Text Screen Display

Pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED Text Screen Display thumbnail-1
Pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED Text Screen Display photo-1
US$ 1,029 - 5,000 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Glareled
Model Number:
GLM-OG224X144RGB
Contact Supplier Request Quote Chat Now
Shenzhen Glare-LED Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Glareled
Model Number GLM-OG224X144RGB
Usage Outdoor
Tube Chip Color Red
Display Function Graphics
Pixels 10mm
Screen Dimension Customized

pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display







Specifications



Pixel Pitch Choice( mm)  12, 14, 16, 20, 22, 25, 31.25
Cabinet Material  Weatherproof  black powder coated steel
Brightness  3000-7000cd/m2
Dimming Control  16 levels - Automatic and 128 levels -Software
Color Depth  16bit / color
Color Displayed   Monochrome (Red, Yellow, Pure Green etc. can be selected) 256 colors
  R-PG/Y-B: 65,536 colors
Viewing Angle  70 o Horizontal, 35 o Vertical or 110 o Horizontal, 50 o Vertical
Video Frame Rate  60Hz
Display Refresh Rate  400Hz
Controlling Mode  Synchronized with the controlling PC through optical fiber cable
  (300m distance with economical multi-mode optical fiber cable) .
  If you need LED display for displaying vivid photo, flash, etc. like our message center, please check our Picture Sign.
Continuous Working Time  Unlimited
Average LED Lifetime  100,000 Hours (manufacturers declared)
File Management Software  Windows-based Software.
  Features: Text Overlay, Sequencing, Scheduling, Preview, Remote control.
Waterproof level  IP65 Front
Power Input  110V/220V AC, 60Hz/50Hz
Working Environment  -20~+60 o C, 15%~95%RH





pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display





Features

Strong practicability We have researched the various outdoor environment ,and design our product system depend on the research   result .so both applicability and reliability of products are improved observably .
vivid color the display cabinet is composed by three basical color (red ,green ,blue).there are 16,777 and 126 kinds color are composed by 256 degree grey for each color Red ,Green and Blue .so the screen can display the video with vivid color , saturate and high resolution
High brightness Used super high brightness Led ,viewing it more clearly under the strong sunlight with far distance .
Good effect More clearly and better hiberarchy image with non-linear proofread technology .
Strong reliability High strongly reliability and stability with static scan technology and module design technology .
Various display mode Support many various display mode .
Expediently operate Simple operation system with current video display software
Application field Government plaza ,easy square ,Large entertainment square ,prosperouse emporia ,advertisement board , shopping mall ,train station etc.
Type P10P12P14P16P18P20P22P25P31.25





pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



More details:



pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



Wooden Package:

 pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



Project Picture:

pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



Shipping&Payment:

1)TT 50% As deposit +50% Balance before shipping after examine goods.

2)West union, L/C at sight etc. are all ok.

3)In general, 5~7 days after deposit, Accurate production time depends on  production schedule .

4)Sample will be shipped by DHL.

5)Normal export wooden and Carton case package .

6)We will always tracking and helping you get the best Purchasing experience.

pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



Certificate:



pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display



Exhibition:



pixel 12, 14, 16, 20, 22, 25, 31.25mm RED LED text screen display





Contact:
