Help CenterDZ Series Single-effect External Circulation Evaporator
Related Products
-
SZG Conical Vacuum DryerUS$ 230,000 - 890,000MOQ: 1 Set -
SZG Series Conical Vacuum DryerUS$ 230,000 - 890,000MOQ: 1 Set
-
GZLS Series Vacuum Freeze Dryer Used in Royal JellyUS$ 4,560,000 - 7,890,000MOQ: 50 Sets
-
GZLS Series Vacuum Freeze Dryer Used in Fresh LookUS$ 230,000 - 890,000MOQ: 50 Sets
-
Vacuum Freeze Dryer Used in Biomedicine ResearchUS$ 230,000 - 890,000MOQ: 50 Sets
Features
This equipment is consists of tubular external heater, vacuum evaporator and auxiliary device. It features short heating time, rapid evaporation speed and can keep the affectivity of thermo sensitive materials well.
It adopts foam-removing with two-grade and reduce the loss of feed liquid greatly
Simple structure, easy cleaning.
Large concentration ratio, the largest could be 1.35g/cm3 .
The parts touched with materials are made of good quality of stainless steel, which meet the heath requirement of pharmacy and food.
Application
This equipment is suitable for the evaporation process of liquid materials in industries of pharmacy, food, chemical industry, light industry, etc.
Technical parameters
|
DZ-350 |
DZ-500 |
DZ-700 |
DZ-1000 |
DZ-1500 |
DZ-2000 |
||
evaporating quantily (kg/h) |
350 |
500 |
700 |
1000 |
1500 |
2000 |
||
steam pressure (MPa) |
0.25 |
0.25 |
0.25 |
0.25 |
0.25 |
0.25 |
||
heating area (m2) |
7 |
8 |
8 |
10.5 |
25 |
35 |
||
condensing area (m2) |
13 |
16 |
16 |
20 |
50 |
70 |
||
cooling area (m2) |
1.5 |
2 |
2 |
3 |
7 |
10 |
||
vacuum degree(MPa) |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
