FL Fluid Bed Granulating Equipment

FL Fluid Bed Granulating Equipment thumbnail-1
FL Fluid Bed Granulating Equipment photo-1
US$ 24,590 - 52,450 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Fertilizer
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Changzhou Yibu Drying Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Product Type Fertilizer
Place of Origin Jiangsu, China
Brand Name YIBU
Model Number FL
Certification IS09001&14001

Specifications

YIBU considers that Fluidized Granulator is an organic combination of mechanical design and manufacture technolog

FL fluidized granulating machine (






“YIBU” considers that Fluidized Granulating is an organic combination of mechanical design and manufacture technology. Therefore hundreds of Granulating machines either for China or exported to USA, Japan, Indonesia, Iran and many other countries are designed in accordance with the process of raw materials.

We have manufactured decades specifications and 150 different machines to meet different needs. These practical experiences will be very beneficial to customers.


The flow ability is improved and the dust is reduced, because of Granulator.

Because of  powder Granulating, its solubility is improved,

Mixing, Granulator and drying processes are completed in one step inside the machine.

The operation is safe because the anti-static filter cloth adopted.

It's safe for operator if explosion take place, because explosion device is adopted.

No need corner. Therefore the loading and unloading are quick, light and clean, meet the requirements of GMP.


Pharmaceutical industry :tablet capsule, low sugar or no sugar granule of Chinese traditional medicine.
Foodstuff:cocoa,coffee,milk powder,juice of granulate,flavoring and so on.
Other industries:pesticide,feed,chemical fertilizer,pigment,dyestuff and so on.
Drying: powder or granule state of wet material
Coating: protection layer, color, controlled release, film, or bowels solved coating of granules and pills.


The powder granule in vessel (fluid bed) appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.

FL fluid bed granulating equipment



item unit  spec
3 5 15 30 60 120 200 300 500 1000
vessel volume L 12 22 45 100 220 420 670 1000 1500 3000

diameter

mm

 300 400 550 700 1000 1200 1400 1600 1800 2200
capability min kg  1.5 4 10 15 30 80 100 150 250 800

max

kg

 4.5 6 20 45 90 160 300 450 750 1200
fan velocity m3/h 1000 1200 1400 1800 3000 4500 6000 7000 8000 13670

pressure

mmH2O

 375 375 480 480 950 950 950 950 950 1400

power

kw

 3 4 5.5 7.5 11 18.5 30 37 45 90
steam consumption

kg/h

 15 23 42 70 141 211 282 366 451 750
compressed air expenditure m3/min 0.9 0.9 0.9 0.9 1.0 1.0 1.1 1.5 3.0 4.0
weight of the main body kg  500 700 900 1000 1100 1300 1500 1800 2500 3500
steam pressure MPA 0.1-0.4
temperature °C adjustable at the range from room temperature to 120°C
working time min 45-90 decided in accordance with the properties of raw materials
collect rate % ≥99
noise dB(A) ≤75dB(A) when do installation ,main machine is separated from fan.
size (L×W×H) m  1.0×0.6
×2.1		 1.2×0.7
×2.3		 1.25×0.9 ×2.5 1.6×1.1
×2.5		 1.85×1.4 ×3 2.2×1.65
×3.3		 2.34×1.7 ×3.8 2.8×2.0
×4.5		 3×2.25
×5.0		 4×2.8×7.2




Pulse Fluidizing Drying Granulator

Typical customers
Northeast General Pharmaceutical Factory
Heilongjiang Haci Group
Jilin Wutai Group
Hayao Group Sanjing Pharmaceutical Co.,Ltd
Shenyang Tianyitang Chinese Medicines Factory
Beijing Juneng Pharmaceutical Co.,Ltd
Shandong Yuwang Pharmaceutical Co.,Ltd
Shandong LuAn Pharmaceutical Co.,Ltd
Qingdao Liuhe Pharmaceutical Co.,Ltd
Shenzhen Haiwang Food Co.,Ltd
Hunan Hengwei Pharmaceutical Co.,Ltd
Hunan Zhengqing Group Pharmaceutical Stock Co.,Ltd
Yichang Humanwell Pharmaceutical Co.,Ltd
Zhuhai Biochemical Pharmaceutical Factory
Guangdong Yili Pharmaceutical Co.,Ltd
Lijinji (Guangzhou)Food Co.,Ltd
Anhui Renji Pharmaceutical Co.,Ltd
Yunnan Dali Xianglong Pharmaceutical Co.,Ltd
Hainan Xiansheng Pharmaceutical Co.,Ltd
Export USA,Mexico,Indonesia,Iran,Peru and so on



Technical conference for explosion proof fluidized granulator and multi-function coater organized by the Provincial Science & Technology Office of Jiangsu.

 USA Daimy Pharmaceutical Co.order two sets of FL200A.

The company had put up big machines
including 4 sets of FL500,2 sets of
FL300 and 6 sets of FL200 into production at Nanyang,Henan;Tongxiang,zhejiang;
Guangxi,sichuan.All of these won good reputation for the company.



FL fluid bed granulating equipment
