Fruit Pressure Atomizing Granulating Dryer/Spray Drier

Fruit Pressure Atomizing Granulating Dryer/Spray Drier thumbnail-1
Fruit Pressure Atomizing Granulating Dryer/Spray Drier thumbnail-2
Fruit Pressure Atomizing Granulating Dryer/Spray Drier thumbnail-3
Fruit Pressure Atomizing Granulating Dryer/Spray Drier photo-1
Fruit Pressure Atomizing Granulating Dryer/Spray Drier photo-2
Fruit Pressure Atomizing Granulating Dryer/Spray Drier photo-3
US$ 230,000 - 890,000 MOQ: 50 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Spray Drying Equipment
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Changzhou Yibu Drying Equipment Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Spray Drying Equipment
Place of Origin Jiangsu, China
Brand Name YI BU
Model Number YPG
Voltage according to customer needs
Power(W) 5.5kw
Dimension(L*W*H) 20m*2.4m*2.4m
Weight one ton
Certification CE:UL;FAD:ISO14001:9001
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas




Because of different products have different drying technologies and particle rules, there is no single type of the spray drying machines that meet all kinds of different requirements. Now spraying is still regards as a kind of technology. The test is the base of correctly choosing the types. The machine equipped by the "YIBU" Company is used specially for the carry out the technological test of the materials. This kind of practical manner makes that we have completed many turn-key projects, such as: detergent powder, polymerized resin, white carbon,Mn3O4,soybean milk, lipase, sea cucumber Chinese traditional medicine and etc.




The material is sprayed into fine mist by nozzle on the top of tower. Follow the heat wind, the material is dried. The machine's characteristic is high collection rate, no stick onto the wall, energy saving, high efficiency, especially applicable for heat sensitive material. It's widely used in food, dyestuff, chemical industry and so on.

spec 50 100 150 200 300 500 1000
Water evaporation capacity Kg/h 50 100 150 200 300 500 1000
Overall dimension mm 1600×8900 2000×11500 2400×13500 2800×14800 3200×15400 3800×18800 4600×22500
High-pressure pump pressure Mpa 2-10
Power Kw 8.5 14 22 24 30 82 30
Inlet air temperature °C 300-350
product water contents % less than 5 percent, and 5 percent can be achieved.
collection rate % >97
electric heater Kw 75 120 150 When the temperature is lower then 200, the parameters should be calculated according to the practical condition.
electricity + steam Mpa+Kw 0.5+54 0.6+90 0.6+108
hot air furnace Kcal/h 100000 150000 200000 300000 400000 500000 1200000



Food Industry,atty milk powder, protein, cocoa milk powder, subsitute milk powder ,egg white (yolk), food and plant ,oats ,chicken juice, coffee ,instant dissoluble tea ,seasoning meat ,protein ,soybean ,peanut protein , hydrolysate and so forth .Sugar ,corn syrup ,corn starch ,glucose .pectin ,malt sugar , sorbic acid potassium and etc.
Medicine,raditional Chinese medicine extract ,ointment ,yeast, vitamin ,antibiotic, amylase ,lipase and etc .
Plastics and resin 'B, ABS emulsion, uric acid resin, phenolic aldehyde resin, urea-formaldehyde resin, formaldehyde resin, polythene, poly-chloroprene and etc.
Detergent'ommon washing powder ,advanced washing powder ,soap powder ,soda ash ,emulsifier ,brightening agent ,orthophosphoric acid and etc.
Chemical industry ,odium fluoride (potassium ), alkaline dyestuff and pigment ,dyestuff intermediate, Mn3O4, compound fertilizer ,formic silicic acid ,catalyst, sulphuric acid agent ,amino acid ,white carbon and so on .
Ceramic ,luminium oxide ,ceramic tile material ,magnesium oxide ,talcum and so on .
Other ,almogastrin, hime chloride , stearic acid agent and the cooling spray .



Guangdong Nanfang Xinyuan Food Biota Engineering Co., Ltd.

Guangzhou Yipin Food Co., Ltd.

Huixu Fine Shine Technology(Shanghai) Co.,Ltd.

Maikesi(Dongyang) Chemical Co., Ltd.

Henan Mengzhou Tailijie Co., Ltd.

Shandong Xinyuan Macromolecule Material Factory

Dandong Kehai Chemical Factory

Zhejing Xinhecheng Stock Co., Ltd.

Hunan Special Metal Material Factory

Nantong Guanghe Biota Technical Co., Ltd.

Wuhan Changjiang Chemical Factory
