Fully Automatic Paper Production Line Toilet Paper Tissue Making Machine
Features:
1.Automatic core feeding system, automatic log pusher after rewinding, then rewind the new log again.
2. Automatic edge-trimming, core feeding; auto edge trimming, glue spraying and sealing synchronously in one time. Leaving 10-18mm tail, easy to rewind again, so reducing shortcut waste and save the cost.
3. Adopts international advanced PLC programmable controlling technique, man-machine interface operation, data set and parametric fault shows on touch screen.
4. Adopts 4 pieces high Precision spiral knives, low noise, clear perforation, adopt gearbox to have bigger range.
5. Three horizontal type back stands, pneumatic loading system, with wide driving flat belts; each jumbo roll can be adjusted independently.
6.Embossment Unit: adopt point to point embossing rollers, making the two layers match well, the paper is soft and has clear patterns
7. Adopt jogging switches for wearing the paper, easy and safe to operate.
Specification:
1. FULLY AUTOMATIC TOILET PAPER REWINDING MACHINE MODEL:1575B
| MACHINE MODEL | 1575B (OTHER SIZE TO BE SPECIFIED) |
| Raw Material Width | 1750mm (Other size to be specified) |
| Finished Roll Diameter | φ90- φ140mm (Other size to be specified) |
| Finished Roll Core Diameter | φ38- φ48mm |
| Raw Material Diameter | ≤ 1100mm (Other size to be specified) |
| Raw Material Core Diameter | φ76mm (Other size to be specified) |
| Perforation Pitch | 4 pieces of Anvil blades(115mm,230mm) Other size to be specified |
| Machine Speed | 0-180m/min |
| Programming Controller | PLC (Delta) |
| Unwinding Unit | 1-3ply (Other size to be specified) |
| Air-System | 0.5-0.8MPA (provide by user themselves) |
| Power | 18kw |
| Dimensions | 10000x3000x2000mm (LxWxH) |
| Machine Weight | 12 Tons ( All machine 40mm Wallboard type insititutions) |
| Basis Weight | 1-3ply, 14-30gsm |
| Edge Embossing Unit | Steel to steel, Independent pneumatic control |
| Embossing Unit | Big roll steel to steel embossing |
| Voltage | 380V,50Hz |
2. NORMAL LOG ACCUMULATOR
| MODEL | LOG ACCUMULATOR-1575 |
| Log Max. Length | 1750mm (Other size can be specified) |
| Log Diameter | φ80- φ115mm (Other size to be specified) |
| Log Amount | 26 logs |
| Working Way | Cycling |
| Program Controller | PLC |
| Power | 3kw |
| Dimension | 3000x2000x2300mm (LxWxH) |
| Weight | about 1.3Tons |
| Voltage | 380V,50Hz |
3. AUTOMATIC BAND SAW CUTTING MACHINE
| MODEL | AUTOMATIC BAND SAW-1575 |
| Jumbo Roll Max. Width | 1750mm |
| Jumbo Roll Diameter | φ80- φ115mm |
| Design Speed | 60 cut/min |
| Stable Speed | 40-50 cut/min |
| Grinding System | Pneumatic Sharpen,grinding time can be set |
| Driving System | Delta Servo Motor |
| Power | 2.2kw |
| Dimension | 3800x2500x2000mm |
| Blade Size | 3900x80x1mm |
| Voltage | 380V,50Hz |
| Weight | about 1.5 Tons |
Toilet Paper Roll Sample
