Remote Starter,remote engine starter Function and Two Way Type smart car alarm system
Model No.: TR-20
TR20 is a hi-performance gps tracker for vehicle management . It can help to get location and condition of the car , you also can get different kinds of report or alarm . You can monitor your car remotely , like cut oil power / lock unlock the door / voice monitor ect . You can get the car's trace playback , and historical data with he help of the tracker . And TR20 has optional function of fuel sensor (to get the level of the oil) / temperature sensor (monitor the temperature of the frozen car) / odometer sensor (to get the odometer of vehicle)
PARAMETER CONFIGURATION (connect the unit to the server via GPRS)
Via PC setup cable and PC setup software to set device ID, APN, IP, port, SMS alarm number, geo-fence, speed limit, battery limit, fixed time/distance report ……etc. (PC setup software will be sent via email or packaged in CD with the sample)
REPORT INCLUDES
1) Unit’s ID
(2) GPS status (valid or last known)
(3) time
(4) latitude and longitude
(5) speed
(6) direction
(7) temperature or fuel level
(8) vehicle’s status
(9) sorts of reports
SPECIFICATION
Enclosure dimensions |
93mm*62mm*25mm |
Weight |
200g |
DC Tolerance voltage |
9V - 35V |
GSM Module |
850/900/1800/1900MHz |
GPS Module |
SIRF III |
Protocol |
NMEA0183 |
Number of Channels |
20 Channel Simultaneous Operation |
Current (GPRS online) |
60mA |
Current (GPRS transmission) |
80mA |
Sleeping mode |
40mA |
Accuracy Horizontal |
<5 meters (50%), <8 meters (90%) |
Altitude |
<10 meters (50%), <16 meters (90%) |
Velocity |
0.06 m/sec. |
Hot Start: |
<13 sec |
Warm Start: |
<42 sec |
Cold Start: |
<84 sec |
Backup battery |
800mAh |
Communication |
GPRS SMSRS232 |
Operating Temperature |
-20°C to +55°C |
Storage Temperature |
-40°C to +65°C |
FUNCTIONS
1 Fixed time/distance report
2 Intelligent report
3 Geo-fence :
4 Direction change report
5 SOS alarm :
6 Lower battery alarm :
7 Over speed report:
9 Built in backup battery.
10 Sleeping mode
11 Door Lock/unlock control
12 Arming (for anti-theft)
13 Panic
14 Anti-car jacking (fuel cut-off)
15 Emergency release (fuel recovery)
16 Temperature sensor (optional)
17 Fuel sensor (optional)
18 Odometer sensor (optional)
Add the tracker to the platform
check the trace on the platform
Check the report on the platform
Any interest in our platform, pls use this demo :
username:doristest
password:1234
More information, pls contact my skype: trackpro18
or send inquiry to me!
