Help CenterDigital Multi-Purpose Multimeter, AC/DC/Resistance/Capacitance/Temperature RS232 UT70B
Related Products
-
Digital Multi-Purpose Multimeter, AC/DC/Resistance/Capacitance/Conductance RS232 UT70CNegotiableMOQ: 1 Piece -
Digital Multi-Purpose Multimeter, AC/DC/Resistance/Capacitance/Conductance True RMS RS232 UT70DNegotiableMOQ: 1 Piece
-
Economical Digital Multimeter, AC/DC/Resistance/Capacitance UT151ANegotiableMOQ: 1 Piece
-
Economical Digital Multimeter, AC/DC/Resistance/Capacitance UT151BNegotiableMOQ: 1 Piece
-
Economical Digital Multimeter, AC/DC/Resistance/Capacitance/Temperature UT151CNegotiableMOQ: 1 Piece
Specifications:
Specifications |
Range |
Best Accuracy |
Model |
UT70B |
|
DC Voltage (V) |
400mV/4V/40V/400V/1000V |
±(0.8%+1) |
AC Voltage(V) |
4V/40V/400V/750V |
±(1%+5) |
DC Current (A) |
400mA/4000mA/40mA/400mA/10A |
±(1%+2) |
AC Current (A) |
400mA/4000mA/40mA/400mA/10A |
±(1.5%+5) |
Resistance (Ω) |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
±(1%+2) |
Capacitance (F) |
4nF/40nF/400nF/4μF/40μF/400μF/4μF/40μF |
±(4%+3) |
Frequency |
4kHz/40kHz/400kHz/4MHz/40MHz/400MHz |
±(0.1%+3) |
Temperture(°C) |
-40°C~1000°C |
±(1%+3) |
Temperture(°F) |
-40°F~1832°F |
±(1%+4) |
RPM |
40kRPM |
±(0.1%+3) |
Features |
|
|
Fused 10A Range |
|
Yes |
Diode |
|
Yes |
Continuity Buzzer |
|
Yes |
Relative measurement |
|
Yes |
Full Icon Display |
|
Yes |
Sleep Mode |
|
Yes |
Low Battery Display |
|
Yes |
Input Impedance for DC Voltage Measurement |
10MΩ |
Yes |
Max/Min Mode |
|
Yes |
Peak Hold |
|
|
Data Hold |
|
Yes |
Display Backlight |
|
Yes |
Auto Ranging |
|
Yes |
Max. Display |
|
3999 |
RS232 |
|
Yes |
Analog Bar Graph |
41 |
Yes |
General Characteristic |
||
Power |
9V Battery (6F22) |
|
LCD Size |
62mm×53mm |
|
Product Color |
Red and Grey |
|
Product Net Weight |
600g (including holster) |
|
Product Size |
195mm×90mm×40mm |
|
Standard Accessories |
Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, RS232C Interface Cable, Software, Holster |
|
Standard Packing |
Gift Box, English Manual |
|
Standard Quantity Per Carton |
20Pcs |
|
Standard Carton Measurement |
535mm×362mm×385mm(Around 0.074 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
20kg |
|
Optional Accessories* |
Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2), Carrying Bag |
|
Contrast:
Specifications |
Range |
Best Accuracy |
|
Model |
UT70A |
UT70B |
|
DC Voltage (V) |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
|
400mV/4V/40V/400V/1000V |
|
±(0.8%+1) |
|
AC Voltage(V) |
200mV/2V/20V/200V/750V |
±(0.8%+3) |
|
4V/40V/400V/750V |
|
±(1%+5) |
|
DC Current (A) |
20mA/2mA/200mA/10A |
±(0.8%+1) |
|
400mA/4000mA/40mA/400mA/10A |
|
±(1%+2) |
|
AC Current (A) |
20mA/2mA/200mA/10A |
±(1%+3) |
|
400mA/4000mA/40mA/400mA/10A |
|
±(1.5%+5) |
|
Resistance (Ω) |
200Ω/2kΩ/20kΩ/200MΩ/2MΩ/20MΩ/200MΩ |
±(0.8%+1) |
|
400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ |
|
±(1%+2) |
|
Capacitance (F) |
20nF/200nF/2μF/100μF |
±(2.5%+5) |
|
4nF/40nF/400nF/4μF/40μF/400μF/4μF/40μF |
|
±(4%+3) |
|
Inductance |
2mH/20mH/200mH/20H |
±(2%+10) |
|
Frequency |
2kHz~10MHz |
±(0.1%+3) |
|
4kHz/40kHz/400kHz/4MHz/40MHz/400MHz |
|
±(0.1%+3) |
|
Temperture(°C) |
-40°C~1000°C |
±(1%+3) |
±(1%+3) |
Temperture(°F) |
-40°F~1832°F |
±(1%+4) |
±(1%+4) |
RPM |
40kRPM |
|
±(0.1%+3) |
Features |
|
||
Fused 10A Range |
|
Yes |
Yes |
Diode |
|
Yes |
Yes |
Transistor |
|
Yes |
|
Continuity Buzzer |
|
Yes |
Yes |
Relative measurement |
|
|
Yes |
Relative Mode |
TTL |
Yes |
|
Full Icon Display |
|
Yes |
Yes |
Sleep Mode |
|
Yes |
Yes |
Low Battery Display |
|
Yes |
Yes |
Input Impedance for DC Voltage Measurement |
10MΩ |
Yes |
Yes |
Max/Min Mode |
|
|
Yes |
Peak Hold |
|
Yes |
|
Data Hold |
|
Yes |
Yes |
Display Backlight |
|
Yes |
Yes |
Auto Ranging |
|
Yes |
Yes |
Max. Display |
|
1999 |
3999 |
|
|
|
|
RS232 |
|
|
Yes |
Analog Bar Graph |
41 |
|
Yes |
General Characteristic |
|||
Power |
9V Battery (6F22) |
||
LCD Size |
62mm×53mm |
||
Product Color |
Red and Grey |
||
Product Net Weight |
600g (including holster) |
||
Product Size |
195mm×90mm×40mm |
||
Standard Accessories |
UT70A-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, Multi-Purpose Socket, Holster |
||
UT70B-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, RS232C Interface Cable, Software, Holster | |||
Standard Packing |
Gift Box, English Manual |
||
Standard Quantity Per Carton |
20Pcs |
||
Standard Carton Measurement |
535mm×362mm×385mm(Around 0.074 CBM Per Standard Carton) |
||
Standard Carton Gross Weight |
UT70A-22.7kg,UT70B-20kg |
||
Optional Accessories* |
Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2), Carrying Bag |
||
Accessories:
Test Lead,
Battery,
Point Contact Temperature Probe,
Test Clip,
RS232C Interface Cable,
Software, Holster
Clip-On Test Lead Light (UT-TL)*,
Built-In Test Lead Light (UT-L1)*,
Built-In Test Lead Light Plus (UT-L2)*,
Carrying Bag*
