Help CenterIndustrial True RMS Digital Multimeter, Datalogger, USB, UT171B
Related Products
-
Industrial True RMS Digital Multimeter, Datalogger, USB, UT171CNegotiableMOQ: 1 Piece -
Industrial True RMS Digital Multimeter, Datalogger, USB, UT181ANegotiableMOQ: 1 Piece
-
True RMS Digital Multimeter, UT139ANegotiableMOQ: 1 Piece
-
True RMS Digital Multimeter, UT139BNegotiableMOQ: 1 Piece
-
True RMS Digital Multimeter, UT139CNegotiableMOQ: 1 Piece
Specifications:
Specifications |
Range |
Best Accuracy |
Model |
UT171B |
|
DC Voltage (V) |
600mV/6V/60V/600V/1000V |
±(0.025%+5) |
AC Voltage (V) |
600mV/6V/60V/600V/750V |
±(0.4%+40) |
DC Current (A) |
600uA/6000uA/60mA/600mA/6A/10A |
±(0.15%+2) |
AC Current (A) |
600uA/6000uA/60mA/600mA/6A/10A |
±(0.75%+5) |
Resistance (Ω) |
600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ |
±(0.05%+2) |
Admittance (nS) |
60nS |
±(1.0%+10) |
Capacitance(F) |
6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF |
±(2.5%+40) |
Frequence (Hz) |
10Hz~10MHz |
±(0.01%+5) |
Temperature (°C) |
-40°C~1000°C |
±(1.0%+30) |
Temperature (°F) |
-40°F~1832°F |
±(1.5%+50) |
Features | ||
Display Count |
|
60000 |
Auto/Manual Range |
|
Yes |
True RMS |
|
Yes |
Bandwidth (Hz) |
100KHz |
Yes |
AC + DC |
|
Yes |
V.F.C |
|
Yes |
4~20mA Loop |
0~100% |
Yes |
LoZ(ACV) |
Around 3KΩ |
Yes |
Diode |
Around 3.0V |
Yes |
Continuity Buzzer |
|
Yes |
Duty Cycle |
1%~99% |
Yes |
NCV |
|
Yes |
Data Hold/MAX/MIN |
|
Yes |
Relative Mode |
|
Yes |
Peak Hold |
|
Yes |
Data Storage |
|
9999 |
Data Comparsion Function |
|
Yes |
USB Interface |
|
Yes |
Display Type |
|
EBTN |
LCD Backlight |
|
Yes |
Analogue Bar Graph |
|
Yes |
Mis-plug Alarm |
|
Yes |
Low Battery Indication |
|
Yes |
Rechargeable Battery |
|
Yes |
Auto Power Off |
Around 15 Minutes |
Yes |
Input Protection |
|
Yes |
Input Impedance for DCV |
Around 1GΩ |
Yes |
General Characteristic | ||
Power |
7.4V 2000mAh Li-ion Battery |
|
LCD Size |
70.6mm x 35.3 mm |
|
Product Color |
Red and Grey |
|
Product Net Weight |
384g |
|
Product Size |
206mm x 95mm x 55mm |
|
Standard Accessories |
Batteries, Test lead, Point Contact Temperature Probe, USB Interface Cable, Power Adaptor(For UT171B/C),PC Software CD |
|
Standard Individual Packing |
Gift Box, Carrying Bag, English Manual |
|
Standard Quantity Per Carton |
20 PCs |
|
Standard Carton Measurement |
530mm × 360mm × 285mm (0.055 CBM Per Standard Carton) |
|
Standard Carton Gross Weight |
22 Kg |
|
Optional Accessories* |
Bluetooth Adaptor (UT-D07) |
|
Contrast:
Specifications |
Range |
Best Accuracy |
||
Model |
UT171A |
UT171B |
UT171C |
|
DC Voltage (V) |
400mV/4V/40V400V/1000V |
±(0.025%+5) |
|
|
600mV/6V/60V/600V/1000V |
|
±(0.025%+5) |
±(0.025%+5) |
|
AC Voltage (V) |
400mV/4V/40V400V/750V |
±(0.4%+40) |
|
|
600mV/6V/60V/600V/750V |
|
±(0.4%+40) |
±(0.4%+40) |
|
DC Current (A) |
400uA/4000uA/40mA/400mA/4A/10A |
±(0.15%+2) |
|
|
600uA/6000uA/60mA/600mA/6A/10A |
|
±(0.15%+2) |
±(0.15%+2) |
|
AC Current (A) |
400uA/4000uA/40mA/400mA/4A/10A |
±(0.75%+5) |
|
|
600uA/6000uA/60mA/600mA/6A/10A |
|
±(0.75%+5) |
±(0.75%+5) |
|
Resistance (Ω) |
400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ |
±(0.05%+2) |
|
|
600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ |
|
±(0.05%+2) |
±(0.05%+2) |
|
Admittance (nS) |
60nS |
|
±(1.0%+10) |
±(1.0%+10) |
Capacitance(F) |
4nF/40nF/400nF/4μF/40μF/400μF /4mF/40mF |
±(2.5%+40) |
|
|
|
6nF/60nF/600nF/6μF/60μF/600μF /6mF/60mF |
|
±(2.5%+40) |
±(2.5%+40) |
|
Frequence (Hz) |
10Hz~10MHz |
±(0.01%+5) |
±(0.01%+5) |
±(0.01%+5) |
Temperature (°C) |
-40°C~1000°C |
|
±(1.0%+30) |
±(1.0%+30) |
Temperature (°F) |
-40°F~1832°F |
|
±(1.5%+50) |
±(1.5%+50) |
Features | ||||
Display Count |
|
40000 |
60000 |
60000 |
Auto/Manual Range |
|
Yes |
Yes |
Yes |
True RMS |
|
Yes |
Yes |
Yes |
Bandwidth (Hz) |
100KHz |
Yes |
Yes |
Yes |
AC + DC |
|
|
Yes |
Yes |
V.F.C |
|
|
Yes |
Yes |
4~20mA Loop |
0~100% |
|
Yes |
Yes |
LoZ(ACV) |
Around 3KΩ |
|
Yes |
Yes |
Diode |
Around 3.0V |
Yes |
Yes |
Yes |
Continuity Buzzer |
|
Yes |
Yes |
Yes |
Duty Cycle |
1%~99% |
Yes |
Yes |
Yes |
Square Wave Output |
|
|
|
Yes |
NCV |
|
Yes |
Yes |
Yes |
Data Hold/MAX/MIN |
|
Yes |
Yes |
Yes |
Relative Mode |
|
Yes |
Yes |
Yes |
Peak Hold |
|
|
Yes |
Yes |
Data Storage |
|
999 |
9999 |
9999 |
Date Time Display |
|
|
|
Yes |
Data Comparsion Function |
|
|
Yes |
Yes |
USB Interface |
|
Yes |
Yes |
Yes |
Display Type |
|
LCD |
EBTN |
OLED |
LCD Backlight |
|
Yes |
Yes |
Yes |
Analogue Bar Graph |
|
Yes |
Yes |
Yes |
Mis-plug Alarm |
|
Yes |
Yes |
Yes |
Low Battery Indication |
|
Yes |
Yes |
Yes |
Rechargeable Battery |
|
|
Yes |
Yes |
Auto Power Off |
Around 15 Minutes |
Yes |
Yes |
Yes |
Input Protection |
|
Yes |
Yes |
Yes |
Input Impedance for DCV |
Around 1GΩ |
Yes |
Yes |
Yes |
General Characteristic | ||||
Power |
UT171A - AA 1.5V x , UT171B/C -7.4V 2000mAh Li-ion Battery |
|||
LCD Size |
UT171A - 70.6mm x 49.5mm,UT171B/C - 70.6mm x 35.3 mm |
|||
Product Color |
Red and Grey |
|||
Product Net Weight |
384g |
|||
Product Size |
206mm x 95mm x 55mm |
|||
Standard Accessories |
Batteries, Test lead, Point Contact Temperature Probe, USB Interface Cable, Power Adaptor(For UT171B/C),PC Software CD |
|||
Standard Individual Packing |
Gift Box, Carrying Bag, English Manual |
|||
Standard Quantity Per Carton |
20 PCs |
|||
Standard Carton Measurement |
530mm × 360mm × 285mm (0.055 CBM Per Standard Carton) |
|||
Standard Carton Gross Weight |
22 Kg |
|||
Optional Accessories* |
Bluetooth Adaptor (UT-D07) |
|||
Accessories:
Batteries,
Test lead,
Point Contact Temperature Probe,
USB Interface Cable,
Power Adaptor
