Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
TENMARS
Model Number:
YF-8070
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Taiwan, China
Brand Name
TENMARS
Model Number
YF-8070
Display Type
Digital Only
Measuring Current Range
10mA to 600A
Measuring Voltage Range
0.1V to 750V
Measuring Resistance Range
1Ω to 2000Ω
Dimensions
221mm * 62mm *35 mm
YF-8070 AC Clamp Meter
Description:
CAT II 600V
3-1/2 digit LCD with maximum reading of 2000.
AC voltage range: 200V, 750V.
AC current range: 20A, 200A, 600A.
Resistance measurement to 2000 ohms.
Data Hold, Peak Hold.
Test Ranges: ACV, ACA, Resistance, Freq, Continuity.
Frequency. (non-contact frequency measurement.
Low battery indication.
Specification:
Maximum Current | 600 Amps |
Display | 2000 counts |
Max. Conductor Size | 35mm |
AC Current | 10mA to 600A, ±(2.0% of rdg + 5 dgts) |
AC Voltage | 0.1V to 750V, ±(1.2% of rdg + 3 dgts) |
Resistance | 1Ω to 2000Ω, ±(1.0% of rdg + 2 dgts) |
Continuity Buzzer | Yes |
Frequency | 1Hz to 5MHz, ±(0.8% of rdg + 3 dgts) |
Peak and Data Hold | Yes |
Dimensions | 221mm (L) x 62mm (W) x 35mm (D) |
Weight | 330g |
