Help CenterTM-1012 400A AC Clamp Meter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
TENMARS
Model Number:
TM-1012
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Taiwan, China
Brand Name
TENMARS
Model Number
TM-1012
Display Type
Digital Only
Measuring Current Range
0.1A to 400A
Measuring Voltage Range
1mV to 600V
Measuring Resistance Range
0.1 ohm to 20 megohms
Dimensions
205mm * 64mm * 39mm
TM-1012 AC Clamp Meter
Description:
CAT III 600V
3-1/2 digit LCD with Analog Bargraph.
Display Counts: 2000.
Auto Ranging.
Data Hold and Range Hold Auto Zero.
Test Ranges: ACV, ACA, DCV, Resistance, Diode, Continuity.
Maximum conductor size 30mm.
Continuity test below 25 ohms, buzzer will sound.
Auto Power off.
Double injection outer case.
Specification:
Maximum Current |
400 Amps |
Display Counts |
2000 |
Maximum Conductor Size |
30mm |
AC Current Range |
0.1A to 400A, ±(2.0% of rdg + 10 dgts) |
AC Voltage Range |
1mV to 600V, ±(1.0% of rdg + 3 dgts) |
DC Voltage Range |
1mV to 600V, ±(0.8% of rdg + 2 dgts) |
Continuity Buzzer |
Yes |
Data Hold |
Yes |
Resistance |
0.1 ohm to 20 megohms ±(1.0% + 3 dgts) |
Diode |
3.0V DC approx |
Dimensions |
205mm )L) x 64mm (W) x 39MM (D) |
Weight |
280g |
