Help CenterTM-27E 600A TRMS AC/DC Clamp Meter
Related Products
TM-27E AC-DC True RMS
Description:
CAT III 600V
3-3/4 digit LCD, Backlit Display with maximum reading of 4000.
True-Rms.
Data Hold, Min/Max, functions.
AC/DC volts, AC/DC current, Resistance, Frequency, Continuity.
Autoranging.
Relative (REL) zero adjust.
Maximum conductor size 35mm.
Low battery indication.
Overload indication.
Continuity buzzer.
Auto power off.
Specification:
Maximum Current |
600 Amps |
Display |
4000 counts |
Max. Conductor Size |
35mm |
AC Current |
0.1A to 600A, ±(2.0% of rdg + 5 dgts) |
AC Voltage |
0.1mV to 600V, ±(1.2% of rdg + 7 dgts) |
DC Current |
0.1A to 600A, ±(1.5% of rdg + 5 dgts) |
DC Voltage |
0.1mV to 600V, ±(0.5% of rdg + 3 dgts) |
Resistance |
0.1Ω to 40MΩ, |
Continuity Buzzer |
Yes |
Frequency |
1Hz to 400KHz |
Backlit Display |
Yes |
Autorange |
Yes |
Auto Power Off |
Yes |
Min/Max |
Yes |
REL (zero adjust) |
Yes |
Data Hold |
Yes |
Dimensions |
218mm (L) x 75mm (W) x 43mm (D) |
Weight |
375g |
